OMEGA CN8DPT145 Temperature Controller
The CN8DPT145 is a versatile temperature and process controller designed for industrial applications. Featuring a 4-digit LED display with wide viewing angles and firmware-automatic configuration, it supports multiple input types including thermocouples, RTDs, thermistors, voltage, current, and strain. It offers control modes like ON/OFF and PID, with auto-tune and fuzzy logic adaptive tuning for precise temperature management. The device provides up to 6 outputs, including relays, DC pulse, and analog signals, with optional Ethernet, serial communication, and remote setpoint features for extensive automation flexibility in industrial control systems.
OMEGA CN8DPT145 Temperature Controller Specifications:
- Display: 4-digit, 9-segment, LED square, 42 DIN size
- Input Types: Thermocouples, RTDs, thermistors, analog voltage/current, strain
- Input Impedance: 10MΩ for process/strain, 5Ω for process current
- Control Modes: ON/OFF, PID, auto-tune, fuzzy logic adaptive tuning
- Outputs: Up to 6 programmable outputs including relays, DC pulse, analog voltage/current
- Control Voltage: 0-10V or 0-20mA scalable, with 0.1% FS accuracy
- Communication: Standard USB, optional Ethernet RJ45, RS232/RS485 serial
- Power Supply: 12-36 Vdc or 90-240 Vac
- Environmental Conditions: 0°C to 50°C, 90% RH (non-condensing)
- Certifications: UL, cUL, CE, NEMA 4X front bezel, IEC recognized
- Dimensions: 48H x 96W x 127mmD (1.89 x 3.78 x 5 inches)
Buy the Buy OMEGA Temperature Process Controller Part Number CN8DPT145 Online
Enhance your industrial automation with the OMEGA CN8DPT145 temperature and process controller. Featuring multiple input options, up to 6 programmable outputs, USB connectivity, and optional Ethernet and serial communication, it provides precise PID control, auto-tune, and fuzzy logic adaptive tuning. Its firmware configuration simplifies setup, eliminating jumpers. Suitable for demanding applications like pharmaceutical, semiconductor, and manufacturing processes, this versatile controller ensures reliable, accurate temperature regulation. Purchase online today for seamless integration into your control system and enjoy our comprehensive support and warranty.
Order your OMEGA Series CN8DPT145 temperature controller today and enhance your industrial process precision with easy setup and versatile features.
Frequently Asked Questions
Where can I buy OMEGA CN8DPT145?
You can click on the BUY or RFQ button to purchase CN8DPT145 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN8DPT145?
You can download the CN8DPT145 datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN8DPT145?
OMEGA
