OMEGA OMCPOCTVOLT32VA2 Voltage Data Logger
The OM-CP-VoltX series 8-channel voltage data logger measures and records voltages from -8 V to +32 V at up to 4Hz sampling rate. Featuring high-resolution 24-bit readings, a rugged black anodized aluminum enclosure, programmable channel names, real-time monitoring, and programmable start times, it offers versatile measurements for various applications. Powered by a user-replaceable 9V lithium battery with an 18-month lifespan, the device uses non-volatile solid-state memory for secure data storage even if the battery depletes. It includes a NIST calibration certificate, USB-A to Micro USB cable, and operates smoothly with OM-CP software. Dimensions are 2.70 x 7.25 x 1.22 inches, weight about 368 grams, making it ideal for professional voltage logging and analysis.
OMEGA OMCPOCTVOLT32VA2 Voltage Data Logger Specifications:
- Number of channels: 8
- Voltage measurement range: -8 V to +32 V
- Sampling rate: Up to 4 Hz
- Resolution: 24-bit readings
- Memory capacity: 349,354 readings per channel
- Power: 9 V lithium battery, 18-month typical life, user-replaceable
- Enclosure: Black anodized aluminum, dimensions 2.70 in x 7.25 in x 1.22 in
- Operating temperature: -20°C to +60°C
- Data storage: Non-volatile solid-state memory
- Connectivity: USB-A to Micro USB cable, interface baud rate 460,800
- Calibration: Digital calibration with date-stamped certificates
- Software: OM-CP Data Logger Software compatible with Windows XP SP3/7/8/10
- Approval: CE, RoHS
Buy the Buy Omega Voltage Data Logger Part Number OM-CP-X16VOLT-32V-A2 Online
Purchase the Omega Voltage Data Logger OM-CP-X16VOLT-32V-A2 today through our online store. This 8-channel device measures voltages from -8 V to +32 V with 24-bit resolution for high-precision data collection. Its durable anodized aluminum enclosure ensures long-term use, while programmable start times and real-time operation provide flexibility. Equipped with non-volatile memory and a user-replaceable battery lasting up to 18 months, it guarantees data security and continuous operation. Compatible with OM-CP software for easy data management, this logger is ideal for professional electrical testing and monitoring in industrial environments.
Order your Omega Series OM-CP-X16VOLT-32V-A2 voltage data logger today and enhance your voltage measurement projects with reliable, high-resolution logging.
Frequently Asked Questions
Where can I buy OMEGA OMCPOCTVOLT32VA2?
You can click on the BUY or RFQ button to purchase OMCPOCTVOLT32VA2 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part OMCPOCTVOLT32VA2?
You can download the OMCPOCTVOLT32VA2 datasheet or visit the OMEGA website for support.
Who is the manufacturer of OMCPOCTVOLT32VA2?
OMEGA
