OMEGA PSW120 Industrial Pressure Switch
The pressure switch PSW120 is designed for reliable pressure control applications, with a range of 10 to 100 psi. Encased in a rugged NEMA 4X (IP66) aluminum enclosure, it features a resistive 15 A switch capable of handling 125/250/480 Vac. The switch offers adjustable deadbands and a manually reset external device, making it suitable for industrial environments. Its vibration-resistant design, gasketed cover, and durable construction ensure long-lasting performance under harsh conditions. Ideal for systems requiring precise pressure switching and environmental protection.
OMEGA PSW120 Industrial Pressure Switch Specifications:
- Approval: UL listed
- Process Temperature: -55 to 205°C (-67 to 401°F)
- Ambient Temperature: -40 to 70°C (-40 to 158°F), models PSW-107 to PSW-117 and PSW-134 to PSW-139: -20 to 70°C ( -4 to 158°F)
- Enclosure: Die-cast aluminum, gasketed, NEMA 4X (IP66) compliant
- Switch Output: One SPDT or DPDT, normally open or normally closed
- Electrical Rating: 15 A resistive at 125/250/480 Vac
- External Manual Reset: 15 A at 125/250 Vac resistive
- Vibration Resistance: Setpoint repeats after 2.5 g, 5 to 500 Hz
- Shock Resistance: Setpoint repeats after 15 g, 10 ms
- Dimensions: 191 mm high, 101 mm wide, 60 mm deep (7.5 x 4 x 2.3 inches)
- Weight: Approximately 0.9 kg (2 lbs)
- Pressure Range: 10 to 100 psi (0.7 to 6.9 bar)
- Maximum Pressure: 600 psi (41 bar)
- Connection: NPT and two 3/4" diameter knockouts
- Switch Type: SPDT or DPDT
Buy the Omega Series PSW Pressure Switch: PSW120
Order the Omega PSW120 pressure switch online today to ensure precise pressure control in demanding industrial environments. With a rugged NEMA 4X enclosure, adjustable deadband, and manual reset, this switch offers long-lasting durability and reliable performance. Its 10 to 100 psi range makes it versatile for various systems, while UL listing guarantees safety and quality. Simplify your installation process and enhance system efficiency by purchasing this durable, vibration-resistant pressure switch from our trusted online store now.
Get Omega PSW120 today—built for reliable pressure switching with durable NEMA 4X enclosure and adjustable deadband for industrial applications.
Frequently Asked Questions
Where can I buy OMEGA PSW120?
You can click on the BUY or RFQ button to purchase PSW120 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PSW120?
You can download the PSW120 datasheet or visit the OMEGA website for support.
Who is the manufacturer of PSW120?
OMEGA
