ONSEMI MM3Z5V1C Voltage Regulator Diode
The MM3Z5V1C is a compact SMD Zener diode designed for general purpose voltage regulation. It features a VZ tolerance of ±5% (C Series), a small and thin package suitable for space-constrained applications, and a matte tin (Sn) finish that is lead-free. Primarily used in industrial applications, this diode provides reliable Zener voltage regulation in various electronic circuits. Due to high market demand, lead times may be extended, and delivery dates could fluctuate. This product is not eligible for discounts.
ONSEMI MM3Z5V1C Voltage Regulator Diode Specifications:
- Package Type: SMD, SOD-323F
- Zener Voltage (Vz): 5.1V (nominal)
- Tolerance: ±5%
- Power Dissipation: 200 mW
- Maximum Junction Temperature: 150°C
- Storage Temperature Range: -65°C to +150°C
- Thermal Resistance Junction to Ambient: 595°C/W
- Lead Finish: Matte Tin (Sn), Pb-Free
- Peak Reverse Voltage: 5.1V
- Marking: Z5V1
- Device Dimensions: Length 1.70 mm ±0.10 mm, Land Pattern Width 0.80 mm, Package Height 0.40 mm
- Temp Range: -65°C to +150°C
- Compliance: RoHS compliant
Buy the Fairchild MM3Z5V1C – Reliable Zener Voltage Regulation for Industrial Applications
Purchase the Fairchild MM3Z5V1C Zener diode online now for reliable voltage regulation in your electronic projects. Its compact SMD package with 5.1V Zener voltage and ±5% tolerance offers excellent performance in space-limited industrial and commercial applications. Lead-free and RoHS compliant, this diode ensures durability and safety. Designed for easy surface-mount installation, it supports high temperature resistance and long-term stability. Order today to ensure timely delivery and integrate a high-quality component into your designs for consistent, dependable voltage regulation.
Get Fairchild MM3Z5V1C today—built for precision and long-lasting durability in voltage regulation.
Frequently Asked Questions
Where can I buy ONSEMI MM3Z5V1C?
You can click on the BUY or RFQ button to purchase MM3Z5V1C from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MM3Z5V1C?
You can download the MM3Z5V1C datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MM3Z5V1C?
ONSEMI
