SCHMERSAL TR23611ZM20 Safety Switch
The safety switch features a thermoplastic enclosure, compliant with EN 50047 standards, and is equipped with a roller plunger actuator. It offers high resistance to oil and petroleum spirits, enabling reliable operation in industrial environments. The switch includes a M20x1.5 cable entry, and its design supports repositionable actuator heads at 4 x 90°, making it versatile for various safety applications. Certified to EN ISO 13849-1, it boasts a mission time of 20 million cycles and a mechanical life of 20 million operations. Suitable for safety interlock functions, it provides a rated impulse withstand voltage of 6kV and an operating current of 10A.
SCHMERSAL TR23611ZM20 Safety Switch Specifications:
- Housing Material: Thermoplastic, self-extinguishing
- Enclosure Standards: EN 50047
- Cable Entry: M20x1.5
- Dimensions: 30 mm x 58.5 mm x 30 mm
- Operation Cycles: 20,000,000
- Mechanical Life: 20 million operations
- Rated Impulse Voltage: 6kV
- Rated Insulation Voltage: 50 V
- Switching Current: 10A
- Switching Principle: Normally open contact (NO), Opener (NC)
- Protection Class: IP67
- Operating Temperature Range: -30°C to +80°C
- Compliance: EN ISO 13849-1
- Certifications: CCC, UL Listed
Buy the Schmersal TR 236-112 U–2013 Reliable Safety Switch for Industrial Applications
Secure your safety systems today by purchasing the Schmersal safety switch online. Designed with durable thermoplastic enclosures and compliant with international safety standards, this switch is ideal for industrial environments requiring reliable interlock solutions. It features a roller plunger actuator, M20 cable entry, and high resistance to oils and petroleum spirits. With a mission time of 20 million cycles and certifications for safety compliance, this switch enhances operational safety and efficiency across diverse automation and machinery setups.
Order your Schmersal TR 236-112 safety switch today and ensure reliable safety interlock functionality in your industrial projects.
Frequently Asked Questions
Where can I buy SCHMERSAL TR23611ZM20?
You can click on the BUY or RFQ button to purchase TR23611ZM20 from an authorized SCHMERSAL distributor.
How do I troubleshoot issues or seek technical support for part TR23611ZM20?
You can download the TR23611ZM20 datasheet or visit the SCHMERSAL website for support.
Who is the manufacturer of TR23611ZM20?
SCHMERSAL
