Schmersal TV7H23611ZM20 Position Switch
The TV7H 236-11z position switch features a thermoplastic enclosure with high resistance to oil and petroleum spirit, designed for positioning tasks with versatile actuators and adjustable lever angles. It complies with EN ISO 13849-1 safety standards and offers a mechanical lifespan of over 20 million operations. The switch has an IP67 protective rating, operates within -30°C to +80°C temperatures, and includes a range of electrical and mechanical configurations for safety and control applications. Its robust construction makes it suitable for demanding industrial environments requiring precise positioning detection.
Schmersal TV7H23611ZM20 Position Switch Specifications:
- Enclosure: Thermoplastic, IP67 rated
- Dimensions: 30mm x 58.5mm x 30mm
- Cable Entry: M20x1.5
- Material: Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
- Contact Material: Silver
- Switching Principle: Normally open (NO), Opener (NC)
- Electrical Life: 20 million operations
- Operating Temperature: -30°C to +80°C
- Rated Insulation Voltage: 50 V
- Rated Impulse Withstand Voltage: 6 kV
- Rated Operating Current: AC-15: 4A, DC-13: 1A
- Protection Class: IP67
- Mechanical Life: Over 20 million cycles
- Switching Frequency: Max 5000 cycles/hour
- Ambient Conditions: Suitable for industrial control applications
Buy the Buy Schmersal Position Switch Part Number TV7H23611ZM20 Online
Discover the Schmersal position switch designed for reliable positioning tasks in industrial environments. With high resistance to oil and petroleum spirit, IP67 protection, and a robust thermoplastic enclosure, it ensures durability and safety compliance. Its versatile actuator options, adjustable lever angles, and extensive electrical and mechanical lifespan make it suitable for demanding control and safety applications. Purchase online now to benefit from easy installation, consistent performance, and long-term reliability essential for safety-critical systems in manufacturing and machinery settings.
Get Schmersal TV7H23611ZM20 today—built for precision and long-lasting durability in industrial positioning and safety applications.
Frequently Asked Questions
Where can I buy Schmersal TV7H23611ZM20?
You can click on the BUY or RFQ button to purchase TV7H23611ZM20 from an authorized Schmersal distributor.
How do I troubleshoot issues or seek technical support for part TV7H23611ZM20?
You can download the TV7H23611ZM20 datasheet or visit the Schmersal website for support.
Who is the manufacturer of TV7H23611ZM20?
Schmersal
