TRACO POWER TBLC50124 Power Supply Module
The TBLC Series power supplies deliver reliable, efficient DC power for industrial and residential applications, with a compact, low-profile design suitable for mounting in panels. They feature universal input voltage, adjustable output, high efficiency, low standby power, and protections against short circuits and overloads. Certified to UL, EN, and IEC standards, these modules operate over -25°C to +70°C, with convection cooling and a simplified DIN-rail mounting system, making them ideal for distributed power needs in various environments.
TRACO POWER TBLC50124 Power Supply Module Specifications:
- Input Voltage Range: 85-264 VAC, 50/60 Hz
- Efficiency: Up to 89%
- Output Power: 6-90 W
- Output Voltage: 5 VDC to 28 VDC (adjustable)
- Output Current: Up to 12 A
- Operating Temperature: -25°C to +70°C, derating above +55°C at 2.5%/K
- Protection: Short circuit, overload, overvoltage
- Dimensions: Vary by model, e.g., 35x18x55 mm for 6W models
- Mounting: DIN-Rail (EN 50022), optional wall mounting with bracket
- Certifications: UL 1310, UL 508, IEC/EN 60950, EN 60204, EN 62477
- Isolation: 3000 VAC
- Pollution Degree: 2
- Vibration Resistance: 3-axis, 2 g sine, 10-150 Hz
- Humidity: 5-95% non-condensing
- MTBF: > 1.9 million hours
- Input Power Consumption (no load): <0.3 W
Buy the Traco Power Series TBLC Power Supply: TBLC50124
Experience reliable, high-efficiency power conversion with the Traco Power Series TBLC power supply modules. Designed for industrial and residential use, these compact units feature adjustable output voltage, universal input, and robust protections, ensuring safe operation across a wide temperature range. Easy DIN-rail mounting and compliance with UL and IEC standards make installation straightforward. Whether for distributed power, home appliances, or industrial automation, purchase your TBLC series power supply online today and secure the stable, efficient energy your applications demand.
Order your Traco Power Series TBLC 50W 24 VDC power supply today and enjoy dependable, efficient power for industrial and residential projects.
Frequently Asked Questions
Where can I buy TRACO POWER TBLC50124?
You can click on the BUY or RFQ button to purchase TBLC50124 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TBLC50124?
You can download the TBLC50124 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TBLC50124?
TRACO POWER
