TRACO POWER TRI61213 high isolation DC/DC converter
The TRI 6 Series is a compact, high-performance 6 Watt DC/DC converter series designed for industrial, transportation, and instrumentation applications. Featuring reinforced isolation up to 9000 VDC for 1s and 7071 VDC for 60s, these converters provide reliable operation with a wide 2:1 input voltage range (9-75 VDC). Offering efficiencies up to 89%, they include integrated safety filters, overload and overvoltage protection, and operate seamlessly within -40°C to +85°C. Their robust design ensures precise regulation, low no-load power consumption, and compliance with IEC/EN/UL safety standards, making them ideal for demanding environments.
TRACO POWER TRI61213 high isolation DC/DC converter Specifications:
- Power Rating: 6 Watts
- Input Voltage Range: 9-18 V, 18-36 V, 36-75 VDC
- Efficiency: Up to 89%
- Isolation Voltage: 9000 VDC (1s), 7071 VDC (60s)
- Operating Temperature: -40°C to +85°C
- Protection: Overload, Overvoltage, Short circuit, Automatic recovery
- Dimensions: Compact DIP-24 package
- Isolation Resistance: 10,000 MOhm min. at 500 VDC
- Insulation Capacitance: 40 pF max. at 100 KHz
- Switching Frequency: 330 kHz typ.
- Housing Material: UL 94V-0 plastic
- Pin Material: Tinned Copper
- Soldering Profile: Wave soldering at 260°C for 10s
- Certifications: IEC 62368-1, UL 62368-1, EN 62368-1, RoHS, Reach
- Protection Features: Overvoltage, overload, short circuit; automatic recovery
- Cooling: Natural convection, altitude max 5000 m
- Weight: 16.59 grams
Buy the TRACO-POWER TRI61213 – Reliable High Isolation DC/DC Converter for Industrial Use
Experience the robust performance of the Traco Power TRI 6 Series, a 6 Watt DC/DC converter designed for demanding industrial and transportation applications. Featuring reinforced isolation capable of withstanding high test voltages up to 9000 VDC, these converters ensure safety and reliability. With efficiencies reaching 89%, they operate efficiently from -40°C to +85°C. Ideal for sensitive electronics, the TRI 6 Series includes integrated safety filters, overload and overvoltage protection, and complies with IEC/EN/UL standards. Purchase online today for dependable power conversion that meets rigorous industrial standards.
Get Traco Power TRI 6 Series today—built for precision and long-lasting durability in demanding environments.
Frequently Asked Questions
Where can I buy TRACO POWER TRI61213?
You can click on the BUY or RFQ button to purchase TRI61213 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TRI61213?
You can download the TRI61213 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TRI61213?
TRACO POWER
