TRACO POWER THL102421WI DC-DC Converter
The Tracopower THL 10-2421WI is a 10W DC-DC converter from the THL 10WI series, designed for industrial applications. It features a compact 1 x 1 inch metal case with an isolated baseplate, providing a reliable power conversion solution. The converter offers a wide input voltage range of 9VDC to 36VDC (nominal 24VDC), with an output of ±5VDC at a maximum current of 1A. Its typical efficiency is 84%, and it includes safety and protection features such as remote On/Off control, short circuit protection, and overvoltage protection. The device complies with UL/cUL 60950-1 and IEC/EN 60950-1 safety standards. It is suitable for instrumentation, distributed power in communication systems, and industrial electronics, also featuring an ultra-wide 4:1 input voltage range, EN 55022 Class A input filter, and high I/O isolation voltage of 1500VDC.
TRACO POWER THL102421WI DC-DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 9VDC to 36VDC
- Output Voltage: ±5VDC
- Output Current Max: 1A
- Efficiency: 84%
- Isolation Voltage: 1500 VDC
- Operating Temperature Range: -40°C to +75°C (up to +85°C with heat sink)
- Isolation Capacitance: 1200 pF max.
- Input/Output Resistance: >1,000 MOhm
- Protection Features: Remote On/Off, short circuit, overvoltage
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Dimensions: 1 x 1 inch (25.4 x 25.4 mm)
- Weight: 15 g
- Operating Environment: Non condensing humidity up to 95%
- Switching Frequency: 400 kHz
Buy the Tracopower Series THL 10WI DC-DC Converter: THL102421WI
Order the Tracopower THL 10-2421WI online today to ensure you get a compact, high-efficiency 10W DC-DC converter. Featuring a wide input voltage range from 9 to 36V, it provides a stable ±5V output at up to 1A. Its UL/cUL and IEC safety certifications guarantee reliable operation in industrial and communication environments. With remote On/Off, short circuit and overvoltage protections, plus high isolation voltage of 1500VDC, it's perfect for distributed power architectures. Invest now for seamless power management.
Buy Tracopower THL102421WI now and experience reliable power conversion with high efficiency and safety protections for industrial and communication systems.
Frequently Asked Questions
Where can I buy TRACO POWER THL102421WI?
You can click on the BUY or RFQ button to purchase THL102421WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102421WI?
You can download the THL102421WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102421WI?
TRACO POWER
