TRACO POWER TEC30915 DC/DC Converter
The TEC 3 series by Traco Power is a compact, 3-watt SIP-8 DC/DC converter designed for high efficiency and reliable performance in industrial and electronic applications. It features an operating temperature range from -40°C to +90°C, 1600 VDC input/output isolation, and fully regulated outputs. With minimal electromagnetic interference and automatic short circuit protection, these converters are ideal for ensuring stable power supply in demanding environments, complying with UL 62368-1. Suitable for industrial automation, control systems, and communication equipment, the TEC 3 series combines performance, safety, and durability.
TRACO POWER TEC30915 DC/DC Converter Specifications:
- Input Voltage: 4.5 - 13.2 VDC or 9-18, 18-36, 36-75 VDC options
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, 48V
- Output Current Max: 700 mA to 300 mA depending on model
- Efficiency: 75% to 86% depending on model
- Isolation Voltage: 1600 VDC (input/output)
- Operating Temperature: -40°C to +90°C
- Storage Temperature: -85°C to +125°C
- Ripple and Noise: 75 mVp-p (20 MHz bandwidth)
- Short Circuit Protection: Yes, automatic recovery
- MTBF: 5,124,000 hours
- Dimensions: 21.8 mm x 10 mm x 13 mm
- Pin Material: Tinned Copper
- Casing Material: Non-conducting black plastic
- Potting Material: Silicone (UL 94V-0)
- Soldering Profile: 260°C / 10 seconds maximum
- Safety Standards: Designed to meet IEC/EN 62368-1, UL 60950-1
Buy the Traco Power TEC 3 Series – Reliable Power Converter for Industrial Applications
Purchase the TEC 3 series DC/DC converters online today and ensure a stable, efficient power supply for your industrial, automation, or control systems. These high-performance converters feature wide temperature ranges, robust isolation of 1600 VDC, and full regulation for optimal operation. With automatic short circuit protection and excellent electromagnetic interference compliance, they deliver dependable power in demanding environments. Order now to benefit from quick delivery, competitive pricing, and the peace of mind that comes with reliable, high-quality power conversion technology.
Buy Traco Power TEC 3 Series now and experience unmatched reliability and high efficiency for industrial power supply solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEC30915?
You can click on the BUY or RFQ button to purchase TEC30915 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEC30915?
You can download the TEC30915 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEC30915?
TRACO POWER
