TRACO POWER TMLM05112 Power Module
The TMLM 05112 is a 5W PCB mount AC/DC power module with a single output, designed for high power density. It features a fully encapsulated plastic case, making it suitable for space-critical applications. The module offers universal input compatibility, low ripple and noise, and includes short-circuit and overload protection. Its high efficiency, approximately 75%, ensures reliable performance, and it is qualified for worldwide markets with international safety approvals. This power module is ideal for power management, industrial, and commercial applications.
TRACO POWER TMLM05112 Power Module Specifications:
- Power Range: 4 to 20 Watts
- Output Power: 5 Watt
- Output Voltage: 12 VDC
- Output Current: 416 mA
- Input Voltage: 90-264 VAC / 120-370 VDC
- Input Frequency: 47-440 Hz
- Efficiency: Up to 75%
- Ripple & Noise: <130 mV (20 MHz bandwidth)
- Protection: Short circuit and overload protection in hiccup mode
- Isolation Voltage: 3,000 VAC
- Operating Temperature: 25°C to +60°C (derating above +50°C)
- Humidity: 95% non-condensing
- Dimensions: Approximately 30 mm x 21 mm x 10.8 mm
- Weight: 30 g
- Safety Certifications: UL 60950-1, IEC/EN 60950-1, CE, CB
- Vibration: 10-55 Hz, 1 g, IEC 60068-2-6
- Shock: 20 G, IEC 60068-2-27
- Environmental: RoHS compliant, Reach compliant
- Casing Material: UL 94V-0 rated plastic resin
- Standards: Electromagnetic compatibility EN 55022 class B, FCC part 15 level B
Buy the Traco Series TMLM AC/DC Power Module: TMLM05112
Purchase the Traco TMLM05112 power module online today and enjoy fast delivery, reliable performance with high efficiency, universal input compatibility, low ripple, noise, and robust safety features. This 5W PCB mount power supply is ideal for industrial, commercial, and power management applications where space-saving solutions are essential. With international safety approvals and superior EMI compliance, buying online ensures you get quality products backed by warranty, supporting your projects with dependable power solutions.
Buy Traco TMLM05112 now and experience unmatched reliability and performance in space-critical industrial applications.
