TRACO POWER TEN402412WIE DC/DC Converter
The TEN 40WIE DC/DC converter series expands Traco Power's existing 40W product range. Designed to deliver high quality and cost efficiency, this series features a 2" x 1" metal enclosure, a 4:1 input voltage range, and high efficiency of up to 92%. It offers excellent thermal performance, operating reliably from -40°C to +70°C without power derating (model dependent), with an even wider operational range up to +85°C. Certified according to IEC/EN/UL 62368-1 standards, these converters include features like remote on/off, short circuit, overvoltage, and over-temperature protection. The series supports natural convection cooling at 20 LFM, switching at 225-275 kHz, and is built with a copper housing and UL94 V-0 rated non-conductive FR4 base, making it suitable for various industrial applications. It also comes with a 3-year warranty and includes a trim function for output adjustment.
TRACO POWER TEN402412WIE DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC, with a 4:1 ratio
- Output Power: 40 Watts (nominal)
- Efficiency: Up to 92%
- Operating Temperature Range: -40°C to +70°C (model dependent), extended to +85°C
- Isolation Voltage: 1600 VDC I/O-isolation
- Protection: Short circuit, overvoltage, overtemperature
- Remote On/Off: Yes
- Dimensions: 2" x 1" x 0.4" (50.8 mm x 25.4 mm x 10.16 mm)
- Housing: Copper, UL 94 V-0 rated non-conductive FR4 base
- Cooling: Natural convection at 20 LFM
- Switching Frequency: 225 - 275 kHz
- Safety Standards: IEC/EN/UL 62368-1
- Certifications: UL, IEC, EN
- Input Surge Voltage: 50 VDC at 24 V; 100 VDC at 48 V
- Input Current: 15 mA at no load (24 V), 10 mA (48 V)
- Start-up Time: 30 ms typical
- Weight: 34 g
Buy the Traco Power Series TEN402412WIE DC/DC Converter: TEN402412WIE
Purchase the Traco Power TEN 40WIE series online today to ensure reliable, efficient power delivery for industrial applications. With high efficiency up to 92%, wide input voltage range, and comprehensive protections including short circuit, overvoltage, and overtemperature, this converter ensures stability across a broad temperature range from -40°C to +85°C. Certified according to IEC/EN/UL standards, it features remote on/off and supports natural convection cooling for robust performance. Trusted for demanding environments, it comes with a three-year warranty, guaranteeing long-term dependable operation for your critical projects.
Order your Traco Power TEN 40WIE series 40 Watt DC/DC converter today and give your projects the dependable power supply they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER TEN402412WIE?
You can click on the BUY or RFQ button to purchase TEN402412WIE from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN402412WIE?
You can download the TEN402412WIE datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN402412WIE?
TRACO POWER
