TRACO POWER TVN50925WI DC/DC Converter
The TVN 5WI series is a compact, 5 Watt DC/DC converter designed for reliable power delivery in industrial and measurement applications. It features ultra-low ripple and noise of 10 mVp-p typical, ensuring stable operation for sensitive circuits. The series includes models with various input voltages (4.5-12 VDC, 9-36 VDC, 18-75 VDC) and adjustable output voltages, providing flexibility for diverse applications. It offers excellent EMI compliance, high efficiency up to 89%, and comprehensive protections including short circuit, overload, and overvoltage. Its robust metal package supports a wide operating temperature range of -40°C to +90°C, ideal for demanding environments, with 1600 VDC isolation, remote On/Off, and low no-load input current, making it suitable for industrial, automation, and test systems.
TRACO POWER TVN50925WI DC/DC Converter Specifications:
- Input Voltage Ranges: 4.5-12 VDC, 9-36 VDC, 18-75 VDC
- Output Voltages: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC, 9-36 VDC, 48 VDC options
- Max Output Current: 416 mA to 1515 mA depending on model
- Efficiency: Up to 89%
- Ripple and Noise: 10 mVp-p typical (with small external capacitor)
- Operating Temperature: -40°C to +90°C
- Isolation Voltage: 1600 VDC
- Protection Features: Short circuit, overload at 170%, overvoltage at 135% Vout
- Remote On/Off, automatic recovery short circuit protection
- Switching Frequency: Approx. 300 kHz
- Package: Metal case, UL rated epoxy potting, approx. 15.39 g weight
- Dimensions: Not specified explicitly, but compatible with DIN rail/mounting standards
- Soldering Temperature: Max. 265°C for 10 seconds
- Certifications: IEC/EN 60950-1, UL 60950-1, RoHS, EN 55032 class B EMI filter
- Input Filter: EN 65033 class B for 48 V models
- Humidity Range: 5-95% RH non-condensing
Buy the Buy Traco Power TVN 5WI Series 5 Watt Part Number TVN50925WI Online
Purchase the Traco Power TVN 5WI Series 5 Watt DC/DC converter online today and enhance your power system's reliability. With ultra-low ripple and noise, high efficiency, wide input voltage options, and comprehensive protections, this converter is ideal for industrial automation, measurement, and detection circuits. Its robust metal package supports a broad temperature range of -40°C to +90°C, ensuring durability in harsh environments. Take advantage of fast delivery and secure checkout options to simplify your project needs and ensure continuous, stable power for sensitive electronic applications.
Order your Traco Power TVN 5WI Series 5 Watt today and ensure reliable, low-noise power for your industrial and measurement projects.
Frequently Asked Questions
Where can I buy TRACO POWER TVN50925WI?
You can click on the BUY or RFQ button to purchase TVN50925WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TVN50925WI?
You can download the TVN50925WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TVN50925WI?
TRACO POWER
