TRACO POWER TEN54811WI DC/DC Converter Module
The POWER TEN 5WI series offers high-performance DC/DC converter modules delivering 5 W output power with ultra-wide input voltage ranges of 9-36 VDC or 18-75 VDC. Featuring a compact DIP-24 metal package, these converters operate efficiently from -40°C to +85°C, making them ideal for battery-powered devices, communication, industrial electronics, and distributed power systems. They boast high efficiency, excellent load and line regulation, built-in filtering to meet EMC standards, and are fully compliant with RoHS. The series supports various output voltages including 3.3V, 5V, 12V, and 15V, with typical efficiencies between 75%-83% and comprehensive safety and isolation features.
TRACO POWER TEN54811WI DC/DC Converter Module Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC
- Output Voltages: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, and others
- Output Current Max: 1200 mA at 3.3 V, 1000 mA at 5 V, 500 mA at 12 V, 400 mA at 15 V
- Efficiency: 75% to 83% depending on model
- Operating Temperature Range: -40°C to +85°C
- Isolation Voltage: 1500 VDC
- Ripple & Noise: 80 mVpk-pk at 20 MHz bandwidth
- Switching Frequency: 450 kHz (typical)
- Case Material: Anodized aluminum, epoxy potting
- Dimensions: DIP-24 package, footprint specified
- Protection: Short circuit, reverse voltage, over-temperature
- Compliance: UL 60950-1, cUL, RoHS, EN 55022 Class A
- Weight: 17 g
- Soldering Temperature: Max 260°C for 10 sec
- Binded with high reliability and full EMC compliance for industrial use
Buy the Traco Power TEN 5WI – Reliable DC/DC Converter for Industrial Applications
Order the Traco Power TEN 5WI series online today and secure high-performance, reliable power solutions suitable for industrial, communication, and battery-powered equipment. These versatile modules deliver 5 W power with ultra-wide input ranges, excellent efficiency, and robust safety features. Their compact DIP-24 metal package enables easy integration into existing designs, ensuring stable operation across a broad temperature range from -40°C to +85°C. Perfect for distributed power architectures, instrumentation, and automation systems where dependability is critical.
Buy Traco Power TEN 5WI now and experience unmatched reliability and compact design for industrial and communication power systems.
Frequently Asked Questions
Where can I buy TRACO POWER TEN54811WI?
You can click on the BUY or RFQ button to purchase TEN54811WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN54811WI?
You can download the TEN54811WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN54811WI?
TRACO POWER
