TRACO POWER TEL102413WI DC/DC Converter
The TEL 10WI series from Traco Power offers compact, high-efficiency 10 Watt isolated DC/DC converters in a DIP-16 metal case. Featuring an ultra-wide 4:1 input voltage range, these converters operate efficiently up to 88°C with minimal thermal loss. They are ideal for space-critical applications in instrumentation, industrial electronics, and IT, meeting standards like EN 55032 Class A with built-in filters. Their robust construction, high reliability, and extensive EMC immunity make them suitable for demanding environments requiring stable power conversion and safety certification.
TRACO POWER TEL102413WI DC/DC Converter Specifications:
- Input Voltage Range: 4:1 wide input range (e.g., 9-36 VDC, 18-75 VDC)
- Output Voltage Options: 3.3 V, 5.1 V, 12 V, 15 V, 24 V, etc.
- Maximum Output Current: 416 mA to 2700 mA depending on model
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +88°C (up to +105°C case temperature)
- Isolation Voltage: 1500 VDC input to output, 1800 VDC input to case
- Pollution Degree: 2
- Dimensions: DIP-16, aluminum alloy, black anodized, 6.5 g weight
- Switching Frequency: 355-485 kHz
- Safety Standards: IEC/EN/UL 60950-1, IEC/EN/UL 62368-1
- EMC Compliance: EN 55032 class A, FCC part 15 class A
- Certifications: RoHS compliant, UL Listed
Buy the Buy Traco Power TEL 10WI Part Number TEL102413WI Online
Enhance your projects with the reliable and compact Traco Power TEL 10WI series 10 Watt DC/DC converters. Featuring high efficiency up to 88%, ultra-wide input range, and reinforced EMC filtering, these converters ensure stable power supply in space-constrained environments. Perfect for industrial, instrumentation, and IT applications, they meet stringent safety and EMC standards. Easy to integrate with a robust aluminum case, they offer high reliability and long MTBF, making them ideal for demanding applications requiring certified safety and enduring performance. Order now to upgrade your power solutions seamlessly.
Order your Traco Power TEL 10WI series 10 Watt isolated converter today and ensure reliable power for your industrial and instrumentation projects.
