TRACO POWER TPP30124J Medical Power Supply
This medical-grade power supply delivers 24V DC output at 1,260mA with high efficiency up to 92%. It features reinforced double I/O isolation, low leakage current below 75pA, and complies with IEC 60601-1 safety standards. Suitable for medical equipment, it operates at temperatures from -40°C to +60°C (up to 85°C with derating), supports altitudes up to 5000 meters, and offers comprehensive EMC immunity and emission compliance. Its compact design ensures dependable performance in healthcare applications requiring safety, stability, and durability.
TRACO POWER TPP30124J Medical Power Supply Specifications:
- Output Voltage: 24 VDC (21.6 - 26.4 VDC)
- Output Current: 1260 mA (max), 90% efficiency
- Output Power: 30 Watts
- Input Voltage: 85 - 264 VAC, 120 - 370 VDC
- Input Frequency: 47 - 63 Hz
- Leakage Current: Less than 75 pA
- Operating Temperature: -40°C to +60°C, derates to 85°C at 50% load
- Protection Class: Class II reinforced insulation
- Altitude: Up to 5000 meters
- Efficiency: Up to 92%
- Certifications: IEC 60601-1, UL 62368-1
- Dimensions: 1.5 x 3.95 inches
- Isolation Test Voltage: 5,657 VDC input to output
- Ripple & Noise: 50 mVp-p typical
- Power Consumption at No Load: 60 mW
- Cooling: Natural convection
- Vibration & Shock: Compliant with IEC standards
Buy the Traco Power Series TPP 30-J Medical Power Supply: TPP 30-124J
Purchase the Traco Power Series TPP 30-124J online today and benefit from a high-quality 24V medical power supply featuring 92% efficiency, reinforced isolation, and low leakage current. Designed for medical equipment, it supports operation up to 5000 meters altitude, compliant with IEC 60601-1 safety standards and EMC regulations. Its compact size of 1.5x3.95 inches allows easy integration into healthcare devices. Get reliable, durable power with proven certification, ensuring safety, performance, and peace of mind in critical medical environments.
Order your Traco Power Series TPP 30-124J medical power supply today and ensure reliable, efficient performance for your healthcare devices.
Frequently Asked Questions
Where can I buy TRACO POWER TPP30124J?
You can click on the BUY or RFQ button to purchase TPP30124J from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP30124J?
You can download the TPP30124J datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP30124J?
TRACO POWER
