TRACO POWER TEL81215 DC/DC Converter
The TEL 8 Series is a range of compact, 8-watt isolated DC/DC converters in DIP-16 metal casings, suitable for space-critical and industrial applications. Featuring a wide 2:1 input range, high efficiency up to 86%, operating temperatures from -40°C to +80°C, and built-in EN 55032 class A filter, these converters provide fully regulated outputs, short circuit and overload protection, and high reliability. They are ideal for instrumentation, IT, and industrial electronics requiring efficient, reliable power conversion with minimal space requirements.
TRACO POWER TEL81215 DC/DC Converter Specifications:
- Input Voltage Range: 3.3 VDC to 36 VDC, 48-75 VDC models available
- Output Power: 8 Watts
- Efficiency: Up to 86%
- Operating Temperature: -40°C to +80°C, derating above 70°C at 5%/K
- Isolation Voltage: 1500 VDC (minimum), tested for 1 second at 1800 Vpk
- Ripple and Noise: 55 mVp-p maximum at 20 MHz bandwidth
- Regulation: Output voltage regulation within 2%, line regulation 0.8%, load regulation 1%
- Protection: Short circuit and overload in hiccup mode, automatic recovery
- Physical Dimensions: Length 16.2 mm, Width 9.0 mm, Height 13.6 mm
- Material: Aluminium alloy casing, tinned copper pins
- Humidity: Up to 95% non-condensing
- MTBF: 1,000,000 hours approximately
- Certification: IEC/EN 60950-1, UL60950-1, RoHS compliant
Buy the Traco Power TEL 8 Series – Reliable DC/DC Converter for Industrial Applications
Enhance your industrial power solutions with the Traco Power TEL 8 Series DC/DC converters. These 8-watt modules in DIP-16 metal casing feature high efficiency up to 86%, wide input ranges, and built-in EMI filters for minimal electromagnetic interference. Designed for space-critical applications, they provide fully regulated outputs, short circuit, and overload protection, ensuring reliable operation across harsh environments. Easy to integrate into instrumentation, IT, and industrial electronics requiring durable, compact, and high-performance power conversion.
Get Traco Power TEL 8 Series today—built for precision, efficiency, and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TEL81215?
You can click on the BUY or RFQ button to purchase TEL81215 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL81215?
You can download the TEL81215 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL81215?
TRACO POWER
