TRACO POWER TEN34813N DC-DC Converter
The TEN 3-4813N from TracoPower is a compact 3W DC-DC converter in a 24-pin DIP package, ideal for industrial and power management applications. It delivers 15VDC output at 200mA, with an efficiency of 85% and supports a wide input voltage range from 36VDC to 75VDC. The device features internal filtering to meet EN 55022, Class A, and FCC Level A standards without external components, and provides high EMC immunity. It offers high reliability with an MTBF over 1 million hours, and ensures safety compliance with UL 60950-1 and IEC 60950-1. The converter supports start-up at 36VDC or lower, with a surge voltage up to 100V, and includes short-circuit protection and high input-output isolation of 1500VDC. Its robust design enables operation across -40°C to +85°C, making it suitable for demanding industrial environments, power supply, and automation system applications, providing reliable performance in space-constrained designs.
TRACO POWER TEN34813N DC-DC Converter Specifications:
- Output Voltage: 15 VDC
- Output Current Max.: 200 mA
- Efficiency: 85%
- Input Voltage Range: 36 VDC to 75 VDC
- Input Current No Load: 15 mA typical at 36 VDC
- Isolation Voltage: 1500 VDC (input/output)
- Isolation Resistance: >1000 MΩ at 500 VDC
- Operating Temperature: -40°C to +85°C
- Surge Voltage Max.: 100 V for 1 sec.
- Ripple and Noise: 70 mVpk-pk at 20 MHz bandwidth
- MTBF: >1 million hours
- Safety Standards: UL 60950-1, IEC 60950-1
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Mounting: DIP-24 package
- Input/Output Capacitance: 300 pF (input/output)
- Soldering Temperature Max.: 260°C / 10 sec.
- Solder Pins Material: Copper alloy with gold plating
Buy the TracoPower Series TEN 3N DC-DC Converter: TEN34813N
Secure the TracoPower TEN34813N DC-DC converter online today to ensure reliable power conversion in demanding industrial environments. With a maximum output of 15VDC at 200mA, high efficiency of 85%, and high isolation voltage of 1500VDC, this compact device is perfect for power management, automation, and industrial systems. Its robust design supports operating temperatures from -40°C to +85°C, includes internal filtering to meet strict EMC standards, and provides automatic short-circuit recovery. Purchase now to benefit from a space-efficient, dependable power solution with safety and EMC compliance guaranteed.
Buy TracoPower TEN34813N now and experience unmatched reliability and performance in space-saving DC-DC conversion for industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34813N?
You can click on the BUY or RFQ button to purchase TEN34813N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34813N?
You can download the TEN34813N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34813N?
TRACO POWER
