TRACO POWER THD122412 DC/DC Converter
The THD-12 series offers high-performance, isolated 12W DC/DC converters in a compact DIP-24 package, ideal for industrial electronics, instrumentation, and communication systems. Designed with high efficiency up to 88%, the units feature wide input ranges, 1500V I/O isolation, and built-in filters. They include remote On/Off, undervoltage lock-out, continuous short-circuit protection, and operate reliably from -40°C to +85°C. Their robust metal case and ceramic capacitors ensure long service life and high reliability in space-constrained applications.
TRACO POWER THD122412 DC/DC Converter Specifications:
- Input Voltage Range: 2.5 VDC to 75 VDC, depending on model
- Output Voltage: 2.5 VDC, 3.3 VDC, 5.1 VDC, 12 VDC, 15 VDC, 18 VDC, 36 VDC, 75 VDC, 48 VDC
- Output Current: up to 3500 mA for 2.5 V models, 2400 mA for 5.1 V, 1000 mA for 12 V, 400-500 mA for higher voltages
- Efficiency: Up to 88%
- Isolation Voltage: 1500 VDC
- Operating Temperature Range: -40°C to +85°C (derated above 65°C)
- Ripple & Noise: 85 mVp-p, 20 MHz bandwidth
- Start-up Voltage: 9 VDC (12 V models), 18 VDC (24 V models), 36 VDC (48 V models)
- Overvoltage Protection: 2.5 & 3.3 V models: 3.9 VDC, 12 V models: 15 VDC
- Short-Circuit Protection: Continuous, automatic recovery
- Switching Frequency: Approx. 400 kHz
- Case Material: Nickel coated copper, epoxy potting
- Dimensions: DIP-24 package, compact design suitable for space-limited applications
Buy the TRACO Series THD12 DC/DC Converter: THD122412
Order the TRACO Series THD122412 DC/DC converter today to ensure your industrial electronics and instrumentation projects benefit from high efficiency, robust isolation, and reliable performance. With a compact DIP-24 package, built-in EMI filters, and protections such as undervoltage lock-out and short-circuit recovery, this converter delivers exceptional value for space-constrained applications. Whether for data communication or battery-operated systems, purchasing online guarantees quick delivery and full technical support, helping you meet your project deadlines with confidence.
Buy TRACO Series THD122412 now and experience unmatched reliability, high efficiency, and compact design for industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER THD122412?
You can click on the BUY or RFQ button to purchase THD122412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD122412?
You can download the THD122412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD122412?
TRACO POWER
