TRACO POWER TEM30512N DC/DC Converter
The TEM 3N series is a cost-effective 3-watt isolated DC/DC converter family in a DIP-24 package, offering fully regulated output, low ripple noise of 30 mVp-p, short circuit protection, and operating temperatures from -40°C to +75°C at full load. Designed for industrial and consumer electronics, models cover input voltages 5V, 12V, and 15V with efficiencies up to 82%. They feature industry-standard pinout, UL60950-1 compliance, and a 3-year warranty, providing reliable power solutions with high reliability and low output noise.
TRACO POWER TEM30512N DC/DC Converter Specifications:
- Input voltage range: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output voltage: 5 V, 12 V, 15 V, 24 VDC
- Output current max: 600 mA, 250 mA, 200 mA, 100 mA
- Efficiency: up to 82%
- Ripple & noise: 30 mVp-p typ.
- Operating temperature range: -40°C to +75°C at full load
- Isolation voltage: 1500 VDC
- Regulation: ±0.5% (input variation), ±3% (load variation)
- Short circuit protection: automatic recovery
- Dimensions: DIP-24 package, weight 12.4g
- Soldering max temperature: 260°C / 10 sec.
- Safety standards: UL60950-1, CSA, IEC 60950-1
- Switching frequency: approx. 300 kHz
- Humidity: 95% rel. max.
- MTBF: over 700,000 hours
- Isolation capacitance: 300 pF typ.
Buy the Buy Traco Power TEM 3N Series Part Number TEM30512N Online
Purchase the Traco Power TEM 3N Series 3-watt isolated DC/DC converter online today to ensure stable and efficient power delivery for your industrial or consumer electronics projects. Featuring full regulation, low ripple noise, and a robust DIP-24 package, this converter ensures dependable performance across a wide temperature range from -40°C to +75°C. Its UL60950-1 compliance and automatic short circuit recovery make it suitable for demanding environments. Secure your reliable power solution now with fast delivery and dedicated support.
Buy Traco Power TEM 3N TEM30512N now and experience reliable performance and high efficiency in industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEM30512N?
You can click on the BUY or RFQ button to purchase TEM30512N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEM30512N?
You can download the TEM30512N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEM30512N?
TRACO POWER
