TRACO POWER TEN30513N DC-DC Converter
The TEN 3-0513N from Tracopower is a versatile 3W DC-DC converter designed for industrial applications, housed in a 24-pin DIP package for easy integration. It features a wide input voltage range of 4.5V to 9V DC, with an output of 15V DC capable of delivering up to 200mA. Built for reliability, it offers efficiency of 82%, continuous short circuit protection, and complies with EN 61000-4-2 ESD and IEC/UL safety standards. Its extended operating temperature from -40°C to +85°C, UL-rated epoxy potting, and high isolation voltage of 1500VDC make it ideal for cost-effective power solutions demanding stable output and high immunity in industrial and control systems.
TRACO POWER TEN30513N DC-DC Converter Specifications:
- Input voltage range: 4.5V to 9V DC
- Output voltage: 15V DC
- Output current: 200mA max.
- Efficiency: 82%
- Isolation voltage: 1500VDC
- Isolation resistance: >1000 MΩ at 500VDC
- Ripple and noise: 70 mVpk-pk (20 MHz bandwidth)
- Operating temperature: -40°C to +85°C
- Start-up voltage: 4.5V or lower
- Surge voltage (1 sec): 11V max.
- Humidity: 95% relative, non-condensing
- Case material: UL 94V-0 rated epoxy potting
- Pin material: Copper alloy with gold plating
- Weight: 12.8 g
- Soldering temperature: Max 260°C / 10 sec.
- Certifications: UL, IEC/EN 60950-1, CSA
- Switching frequency: 90 kHz
Buy the Tracopower Series TEN 3N DC-DC Converter: TEN30513N
Get your Tracopower Series TEN 3N TEN30513N DC-DC converter online today. With a 3W power rating, 15V output, and wide input range from 4.5V to 9V, this converter offers outstanding efficiency of 82% and robust features like high isolation voltage of 1500VDC, UL and IEC safety approval, and operation from -40°C to +85°C. Its epoxy potting case and gold-plated pins ensure durability in industrial settings. Perfect for power management solutions needing reliable, safe, and compact design. Purchase now for quick, trusted delivery and optimal project performance.
Order your Tracopower Series TEN 3N TEN30513N today and ensure reliable power supply with high efficiency and extended temperature range in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN30513N?
You can click on the BUY or RFQ button to purchase TEN30513N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN30513N?
You can download the TEN30513N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN30513N?
TRACO POWER
