TRACO POWER TME1205S Isolated Power Converter
The TME series offers ultra-compact, isolated DC/DC converters in SIP packages, ideal for space-constrained applications requiring reliable voltage regulation. Designed with high efficiency up to 80% and operating over -40°C to +85°C, these devices feature 1000 VDC input/output isolation, industry-standard pinouts, and are fully tested for high reliability. Suitable for generating supplementary isolated voltages, they are ROHS compliant, lead-free, and provide a cost-effective, high-performance power solution for industrial and electronic applications.
TRACO POWER TME1205S Isolated Power Converter Specifications:
- Input Voltage Range: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V
- Output Current Max.: 260 mA (3.3 V), 200 mA (5 V), 110 mA (9 V), 84 mA (12 V and 15 V), 84 mA (24 V)
- Isolation Voltage: 1000 VDC
- Efficiency: Up to 80%
- Operating Temperature: -40°C to +85°C
- Ripple & Noise: 150 mVp-p (20 MHz bandwidth)
- Thermal Derating: 3.3%/K (5 V), 4.0%/K (others) above 70°C
- Dimensions: Small package, approximately 0.7 cm² footprint
- Soldering Temperature: Max 265°C for 10s
- Insulation Resistance: >1,000 Mohm
- Isolation Capacitance: 60 pF
- Shielding Material: Non-conductive UL 94V0 rated plastic
- Switching Frequency: 50 to 110 kHz
- Reliability: MTTF > 2,000,000 hours
Buy the Traco Power TME1205S – Reliable Isolated Power Converter for Industrial Applications
Enhance your power supply system with the Traco Power TME1205S, a highly reliable, compact, and efficient isolated DC/DC converter designed for industrial and electronic applications. Its SIP package saves space while providing up to 80% efficiency and 1000 VDC isolation. The device operates over a wide temperature range from -40°C to +85°C, ensuring stable performance in demanding environments. Perfect for generating isolated voltages, it is ROHS compliant, fully tested, and ideal for high-reliability industrial power solutions.
Buy Traco Power TME1205S now and experience unmatched reliability, high efficiency, and space-saving power conversion for your industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER TME1205S?
You can click on the BUY or RFQ button to purchase TME1205S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME1205S?
You can download the TME1205S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME1205S?
TRACO POWER
