TRACO POWER TEN32411 DC/DC Converter
The TEN 3 series DC/DC converters provide a reliable 3-watt power solution suitable for industrial and communication applications, featuring ultra-wide input ranges from 4.5 V to 72 VDC, high efficiency up to 84%, and robust operating temperatures from -40°C to +85°C. These compact, full SMD-design converters include internal filtering to meet EN 55022-A and FCC Class A standards, with 1500 VDC isolation, short circuit protection, and a 3-year warranty. Designed for high reliability, they are ideal for space-constrained systems requiring stable, noise-free power conversion.
TRACO POWER TEN32411 DC/DC Converter Specifications:
- Power output: 3 Watt
- Input voltage range: 4.5 - 72 VDC
- Output voltages: 3.3 V, 5 V, 12 V, 15 V, 24 V, 36 V, 48 V
- Maximum output current: from 200 mA to 600 mA depending on model
- Efficiency: up to 84%
- Isolation voltage: 1500 VDC for 60 seconds
- Operating temperature: -40°C to +85°C
- Ripple and noise: 50 mVpk-pk (20 MHz bandwidth)
- Switching frequency: 300 kHz (typical)
- Humidity: up to 95% non-condensing
- Case material: non-conductive FR4
- Potting material: epoxy (UL 94V-0 rated)
- Weight: 12 grams
- Soldering temperature: max 265°C for 10 seconds
- Certifications: UL, cUL, IEC/EN 60950-1, CSA
- MTBF: >1.1 million hours
Buy the Traco Power Series TEN 3 3W DC/DC Converter: TEN32411
Purchase the Traco Power Series TEN 3 3W DC/DC Converter online today for reliable power conversion in industrial and communication systems. Featuring ultra-wide input voltage ranges from 4.5 V to 72 VDC, these high-efficiency converters deliver up to 84% efficiency and include robust safety features like 1500 VDC isolation and short circuit protection. Their compact design, full SMD construction, and compliance with EN 55022-A and FCC standards make them ideal for space-constrained, noise-sensitive applications. Enjoy quick, secure online ordering with extended temperature operation from -40°C to +85°C, ensuring long-term dependable performance in demanding environments.
Order your Traco Power Series TEN 3 3W DC/DC Converter today and give your industrial projects the dependable, noise-free power they need.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32411?
You can click on the BUY or RFQ button to purchase TEN32411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32411?
You can download the TEN32411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32411?
TRACO POWER
