TRACO POWER TEN32412 DC/DC Converter
The Power Ten 3 series provides high-efficiency DC/DC converters ideal for industrial and communication applications. With a 2:1 input voltage range, full SMD design, and extended operating temperature from -40°C to +85°C, these converters feature high reliability with MTBF over 1.1 million hours. They include input filtering according to EN 55022-A and FCC Level A standards, short circuit protection, and optional isolation of 1500 VDC. This series offers multiple output voltages, typ. efficiency up to 84%, and robust performance in demanding environments, ensuring stable power delivery with high safety standards.
TRACO POWER TEN32412 DC/DC Converter Specifications:
- Input Voltage Range: 3.0 - 6.0 VDC, 4.5 - 9.0 VDC, 9 - 18 VDC, 12 VDC, 24 VDC, 36-72 VDC, 48 VDC
- Output Voltages: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 18 VDC, 24 VDC, 36 VDC, 72 VDC
- Output Current Max: 600 mA to 250 mA depending on model
- Efficiency: Up to 84%
- Isolation Voltage: 1500 VDC for 60 seconds
- Operating Temperature: -40°C to +85°C
- Ripple & Noise: 60 mVpk-pk at 20 MHz bandwidth
- Input Noise Filter: Meets EN 55022-A, FCC Level A
- Soldering Temperature: Max 265°C for 10 sec.
- MTBF: >1.1 million hours, Certified safety standards UL 60950-1, IEC/EN 60950-1
- Switching Frequency: 300 kHz typ.
- Protection: Short circuit, reverse voltage up to 1 A, indefinite protection
- Enclosure: Non-conductive FR4 epoxy (UL 94V-0 rated) with weight 23.9 g
- Humidity: Up to 95% non-condensing
- Reliability: Designed to operate reliably in industrial environments
- External Standards: Reach, RoHS 2011/65/EU
Buy the Buy TracoPower Power Ten 3 Series Part Number TEN32412 Online
Enhance your power solutions with the highly reliable TracoPower Power Ten 3 series. Featuring wide input ranges, high efficiency up to 84%, and robust design, these converters ensure stable performance in industrial applications. The series provides excellent EMI filtering, 1500 VDC isolation, and operation across -40°C to +85°C, making them suitable for challenging environments. With proven safety standards, long MTBF, and comprehensive protection features, these converters are the perfect choice for demanding power management needs. Purchase online today for dependable, high-quality performance.
Get TracoPower Power Ten 3 Series TEN32412 today—built for precision and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32412?
You can click on the BUY or RFQ button to purchase TEN32412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32412?
You can download the TEN32412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32412?
TRACO POWER
