TRACO POWER TEN34810WI DC-DC Converter Module
The TEN 3WI series from Tracopower comprises 3W single and dual output DC-DC converters housed in a 24-pin DIP package. These converters feature a wide 4:1 input voltage range, with nominal inputs of 24VDC or 48VDC. They provide various output voltages including 3.3VDC, 5VDC, 12VDC, 15VDC, ±12VDC, and ±15VDC, with maximum output currents up to 750mA. The converters offer high efficiency levels up to 84%, supporting an operating temperature range from -40°C to +70°C at full load. They include automatic, indefinite recovery short circuit protection, current limiting, and internal filtering adhering to EN 55022-A and FCC Level A standards. The devices feature an I/O isolation voltage of 1500VDC (60 seconds), a typical isolation capacitance of 380pF, and isolation resistance greater than 1000 MΩ at 500VDC. Ripple and noise are limited to a maximum of 75mV peak-to-peak over a 20MHz bandwidth. Certified according to cUL/UL 60950-1 and IEC/EN 60950-1 safety standards, they measure 20.3mm x 10.2mm x 31.8mm and are supported by a 3-year warranty. Typical applications include battery-operated equipment, distributed power architectures in communication, instrumentation, and industrial electronics requiring isolated, tightly regulated voltages.
TRACO POWER TEN34810WI DC-DC Converter Module Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC
- Output Voltages: 3.3V, 5V, 9V, 12V, 15V, -12V, -15V
- Maximum Output Current: 750 mA
- Efficiency: Up to 84%
- Operating Temperature: -40°C to +70°C at full load
- Isolation Voltage: 1500 VDC (60 sec.)
- Isolation Capacitance: 380 pF typical
- Isolation Resistance: >1000 MΩ at 500VDC
- Ripple & Noise: 75 mV peak-to-peak
- Regulation: 1% line and load regulation
- Short Circuit Protection: Indefinite, automatic recovery
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Potting Material: Epoxy
- Soldering Temperature: Max 265°C / 10 sec.
- Safety Standards: UL 60950-1, IEC/EN 60950-1
- Environmental Compliance: RoHS, Reach
- Reliability: MTBF > 1 million hours
Buy the Tracopower Series TEN 3WI DC-DC Converter: TEN34810WI
Purchase the Tracopower TEN34810WI DC-DC converter online today and enjoy reliable power conversion with high efficiency up to 84%. Its wide input range of 9-36VDC ensures versatility for various industrial, communication, and instrumentation applications. Featuring 1500VDC isolation, low ripple and noise, and automatic short circuit protection, this converter guarantees safe and stable operation in demanding environments. Supported by a 3-year warranty, it’s ideal for battery-operated devices and distributed power systems that require high performance and safety compliance. Order now for quick delivery and seamless integration into your projects!
Buy Tracopower TEN34810WI now and experience unmatched reliability and performance with high efficiency and robust safety features.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34810WI?
You can click on the BUY or RFQ button to purchase TEN34810WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34810WI?
You can download the TEN34810WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34810WI?
TRACO POWER
