TRACO POWER TEN34812WIN DC-DC Converter
The TEN 3-4812WIN from TracoPower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. It serves as a cost-effective drop-in replacement for the popular TEN 3WI series, featuring a modern design that reduces costs without sacrificing reliability or functionality. This converter boasts an ultra-wide 4:1 input voltage range, from 18VDC to 75VDC, with an input current of 20mA at no load. It delivers a stable 12VDC output with a maximum current of 250mA, achieving an efficiency of 83%. The device meets EN 55022, class A, and FCC level A EMC standards without external components, thanks to its input filter. It also offers enhanced EMC immunity, extended operation from -40°C to +85°C, and features like continuous, automatic recovery short circuit protection and no minimum load requirement. The converter is certified to safety standards such as UL 60950-1 and IEC 60950-1, has a dimension of 20.3mm x 10.2mm x 31.8mm, and includes high input-to-output isolation of 1500VDC with greater than 1000 MΩ resistance. Additional features include a minimum switching frequency of 90kHz, surge handling up to 100V for 1 second, and compliance with EN 61000-4-2 ESD immunity standards of ±8kV air and ±6kV contact. Its non-conductive FR4 case is epoxy potted with UL 94V-0 rated material, and it has gold-plated copper alloy pins. Suitable for power management and industrial applications, this converter offers reliable performance in demanding environments.
TRACO POWER TEN34812WIN DC-DC Converter Specifications:
- Input Voltage Range: 18VDC to 75VDC (ultra-wide 4:1 ratio)
- Output Voltage: 12 VDC
- Output Current Max: 250mA
- Efficiency Max: 83%
- Input Current No Load: 20mA at 48V
- Input Surge Voltage: 100V for 1s
- Isolation Voltage: 1500VDC
- Isolation Resistance: >1,000 MΩ
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- CE/UL/IEC 60950-1 safety standards
- Operating Temp Range: -40°C to +85°C
- Ripple & Noise: 70mV peak-to-peak
- Switching Frequency: 90kHz minimum
- EN 55022 Class A EMC, EN 61000-4-2 ESD immunity
Buy the Buy TracoPower DC-DC Converter Part Number TEN34812WIN Online
Purchase the TracoPower TEN 3-4812WIN 3W DC-DC Converter online today for premium power management. Featuring a wide input range from 18V to 75V and a stable 12V output, this converter ensures reliable performance in industrial environments. Its high efficiency of 83%, low no-load current, and robust EMC immunity comply with EN 55022, class A standards. Suitable for demanding applications, it offers high isolation of 1500VDC, compact size, and safety certifications, providing peace of mind and excellent value for your power solutions.
Order your TracoPower TEN 3-4812WIN series 12VDC power converter today and ensure reliable power delivery for demanding industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34812WIN?
You can click on the BUY or RFQ button to purchase TEN34812WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34812WIN?
You can download the TEN34812WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34812WIN?
TRACO POWER
