TRACO POWER TMLM20105 Power Module
The TMLM Series power modules deliver 4 to 20 Watt fully encapsulated AC/DC power supplies, ideal for space-critical PCB applications in industrial and commercial electronics. These modules feature universal input 90-264 VAC, high efficiency up to 83%, low ripple and noise, and meet international safety standards including UL 60950-1. With EMI compliance to EN 55022 Class B and FCC Level B, they offer reliability with high MTBF, short circuit protection, and broad temperature operation from 25°C to +60°C. SMD technology ensures high durability and performance in varied environments.
TRACO POWER TMLM20105 Power Module Specifications:
- Power Output: 4 to 20 Watt
- Input Voltage: 90-264 VAC, 47-440 Hz
- DC Input Range: 120-370 VDC
- Efficiency: Up to 83%
- Ripple & Noise: <250 mV (varies by model)
- Isolation Voltage: 3000 VAC (Input/Output)
- Operating Temperature: 25°C to +60°C, derating above +40°C to +50°C models
- Humidity: 95% rel. max.
- Switching Frequency: 132 +8 kHz
- MTBF: >250,000 hours (TMLM 20 models)
- Compliance: UL 60950-1, EN 55022 Class B, FCC Level B
- Casing Material: Fiberglass reinforced plastic (UL 94V-0)
- Dimensions: Approximates 40 mm x 30 mm x 20 mm for typical models
- Mechanical: Fully encapsulated, suitable for PCB soldering
- Safety & Approvals: Certified for worldwide markets, includes UL, cUL, and CB certifications
- Protection: Short circuit, overload, overvoltage via Zener diode (main output)
Buy the Buy Traco Power TMLM Series Power Module Part Number TMLM20105 Online
Secure your project’s power needs by ordering the Traco Power TMLM 20105 power module online today. This high-efficiency, fully encapsulated power supply offers broad input voltage compatibility, low ripple, and noise, ensuring stable operation in space-constrained environments. With safety standards like UL 60950-1 and EMI compliance, it’s perfect for industrial and commercial use. Its robust construction, short circuit protection, and broad temperature range make it a dependable choice for reliable power delivery. Purchase now for fast delivery and quality assurance.
Order your Traco Power TMLM 20105 compact power module today and ensure reliable power supply for your industrial and commercial projects.
Frequently Asked Questions
Where can I buy TRACO POWER TMLM20105?
You can click on the BUY or RFQ button to purchase TMLM20105 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMLM20105?
You can download the TMLM20105 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMLM20105?
TRACO POWER
