TRACO POWER TEN34823N Dual Output DC-DC Converter
The TEN 3-4823N from TracoPower is a 3W dual output DC-DC converter housed in a 24-pin DIP package. It features a wide input voltage range of 36VDC to 75VDC, with an input current of 15mA at no load. Providing ±15VDC output at a maximum of 100mA, it achieves 84% efficiency and boasts an MTBF over one million hours. This reliable converter includes EMC filtering, high electromagnetic immunity, and an extended temperature range from -40°C to +85°C. It complies with multiple safety standards, offers input/output isolation of 1500VDC, and has automatic short circuit recovery, making it ideal for demanding industrial applications requiring high reliability and cost efficiency.
TRACO POWER TEN34823N Dual Output DC-DC Converter Specifications:
- Input voltage range: 36VDC to 75VDC
- Input current no load: 15mA at 36V
- Maximum output current: 100mA per output
- Output voltage: ±15VDC
- Efficiency: 84%
- Isolation voltage (input/output): 1500VDC
- Isolation resistance: >1 GΩ at 500VDC
- Operating temperature: -40°C to +85°C
- Case dimensions: 20.3mm x 10.2mm x 31.8mm
- Soldering temperature: max. 260°C / 10 sec.
- Switching frequency: 90 kHz minimum
- EMC compliance: EN 55022 Class A, FCC Level A
- Safety standards: UL 60950-1, IEC 60950-1, CSA
- MTBF: over 1 million hours
- Start-up voltage: 36VDC or lower
- Surge voltage (1 sec): 100V max.
- Protection: continuous, automatic recovery short circuit protection
Buy the TracoPower TEN 34823N – Reliable DC-DC Converter for Industrial Applications
Enhance your industrial power solutions with the TracoPower TEN 34823N dual output DC-DC converter. Designed for efficiency and reliability, it features broad input voltage range, high EMI immunity, and extended temperature operation from -40°C to +85°C. With built-in EMC filtering, high input/output isolation of 1500VDC, and automatic short circuit protection, it ensures stable operation in critical applications. Its compact size and compliance with safety standards make it an optimal choice for demanding industrial, automation, and instrumentation systems. Purchase online today for dependable, cost-effective power conversion.
Buy TracoPower TEN 34823N now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34823N?
You can click on the BUY or RFQ button to purchase TEN34823N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34823N?
You can download the TEN34823N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34823N?
TRACO POWER
