TRACO POWER TBLC75112 Power Supply Module
The TBLC Series from Traco Power offers compact, high-efficiency DIN-rail power supplies ranging from 6 to 90 W, suitable for industrial and residential applications. These low-profile modules feature adjustable output voltages, universal input voltage 85 to 264 VAC, and operate within -25°C to +70°C. Certified for safety with UL 508 and UL 1310, they provide short circuit, overload protection, and come with a DC-OK indicator LED. Designed for reliable performance, they are compliant with ECO standards and DIN 43880 mounting specifications, ideal for distributed power in automation and household appliances.
TRACO POWER TBLC75112 Power Supply Module Specifications:
- Input voltage nominal range: 85-264 VAC; effective range 100-240 VAC, 50/60 Hz
- Output power: 6W to 90W
- Output voltage: adjustable from 5.0 VDC to 28.0 VDC, depending on model
- Output current: up to 12A
- Efficiency: up to 89%
- Operating temperature: -25°C to +70°C
- Protection: short circuit, overload, and overvoltage protections
- Dimensions: width varies from 18mm to 90mm, depth 55 mm, conform to DIN 43880
- Certification: UL 508, UL 1310, IEC 60950-1, EN 60204, RoHS compliant
- Mounting: DIN-rail and optional wall/mount with supplied bracket
- Input frequency: 47-63 Hz
- Leakage current: max. 0.25 mA
- Isolation: 3000 VAC
- Vibration: 3-axis sine and half sine testing
- Protection class: safety class II
- IP Protection: IP 20
- MTBF: >1.9 million hours
Buy the Traco Power TBLC Series – Reliable Power Supplies for Industrial Applications
Enhance your projects with Traco Power's TBLC Series power supplies. These compact, DIN-rail modules deliver reliable, high-efficiency power from 6 to 90 W, suitable for both industrial and residential applications. Featuring adjustable output voltage, UL certification, and comprehensive protections including short circuit and overload, they are designed for maximum durability in demanding environments. Easy to install on DIN rails or walls with included brackets, these power supplies ensure stable operation, conform to ECO standards, and are ideal for automation, household appliances, and distributed power systems. Purchase online today for dependable power solutions.
Order your Traco Power TBLC Series 6-90 Watt power supply today and ensure reliable, efficient power delivery in your industrial or residential projects.
Frequently Asked Questions
Where can I buy TRACO POWER TBLC75112?
You can click on the BUY or RFQ button to purchase TBLC75112 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TBLC75112?
You can download the TBLC75112 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TBLC75112?
TRACO POWER
