TRACO POWER TEN61222N DC-DC Converter
The TEN 6-1222N from TracoPower is a high-performance, dual-output 6W DC-DC converter housed in a 24-pin DIP package. Designed for an optimal balance of cost and performance, it offers features such as overload protection, internal filtering compliant with EN55022 Class A, no minimum load requirement, and high efficiency. The converter is a direct replacement for many cost-sensitive applications, featuring a wide 2:1 input voltage range and precise output voltage regulation. It provides continuous, automatic recovery short circuit protection and uses UL 94V-0 rated non-conductive plastic casing with UL 94V-0 epoxy potting for enhanced safety. Typically used in distributed power architectures, workstations, computer equipment, and communications devices, it operates with an input voltage range from 9VDC to 18VDC, delivering ±12VDC output at a maximum current of ±250mA with an efficiency of 82%. It features 1500VDC I/O isolation, a switching frequency of 330kHz, and compliance with UL/cUL 60950-1 and IEC/EN 60950-1 standards. The unit is capable of startup at 9VDC or lower, withstands surge voltages up to 25V for 1 second, and has an input-to-output resistance exceeding 1000 MΩ at 500VDC. Its dimensions are 20.3mm x 10.2mm x 31.8mm (W x H x D), with an operating temperature range from -40°C to +85°C.
TRACO POWER TEN61222N DC-DC Converter Specifications:
- Power: 6 Watt
- Input Voltage Range: 9VDC to 18VDC
- Output Voltage: ±12 VDC
- Output Current Max: ±250 mA
- Efficiency: 82%
- Input/Output Isolation: 1500 VDC
- Switching Frequency: 330 kHz
- Operating Temperature Range: -40°C to +85°C
- Case Material: UL 94V-0 rated plastic, epoxy potting
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Surge Voltage Max: 25 V (1 sec)
- Isolation Resistance: >1000 MΩ at 500 VDC
- Soldering Temperature: Max 260°C
- Certifications: UL, cUL, IEC/EN 60950-1, RoHS, Reach
- Features: Overload protection, internal filter EN55022 class A, no minimum load
Buy the TracoPower Series TEN Series DC-DC Converter: TEN61222N
Enhance your electronic systems with the TracoPower TEN61222N high-efficiency dual-output 6W DC-DC converter. Featuring overload protection, UL safety compliance, and a wide input voltage range, it ensures reliable power supply for industrial, communication, and computing applications. Its compact DIP-24 package, UL-rated plastic case, and semiconductor technology make installation simple and secure. Suitable for complex power architectures, this converter delivers stable output voltages up to 12V and isolates inputs from outputs up to 1500VDC, providing dependable operation from -40°C to +85°C. Order online now for fast delivery and optimal performance.
Buy TracoPower TEN61222N now and experience unmatched reliability and performance in your power management solutions.
