TRACO POWER TEN61223N DC/DC Converter
The Traco Power TEN 6-1223N is a high-performance dual output DC to DC converter enclosed in a 24-pin DIP package. It offers a 6W power capacity with an input voltage range from 9VDC to 18VDC and provides a regulated output of ±15VDC at a maximum current of 200mA. Designed for cost-effective and efficient power conversion, it features overload protection, internal filtering compliant with EN55022 Class A standards, and does not require a minimum load. The converter has a wide 2:1 input range, tight voltage regulation, and automatic recovery from short circuits. Its UL 94V-0 rated non-conductive plastic case and epoxy potting ensure safety and durability. This unit is ideal for distributed power architectures, workstations, computer equipment, and communication devices. Operating with an efficiency of approximately 82%, it supports a start-up voltage of 9VDC or less, with a maximum surge of 25V for 1 second. The input/output isolation is rated at 1500VDC with high resistance and capacitance specifications. Its compact dimensions are 20.3mm x 10.2mm x 31.8mm, and it operates effectively across a temperature range of -40°C to +85°C. Certified under UL/cUL 60950-1 and IEC/EN 60950-1, this power converter is suitable for industrial and power management applications.
TRACO POWER TEN61223N DC/DC Converter Specifications:
- Input Voltage Range: 9VDC to 18VDC
- Output Voltage: ±15VDC
- Output Current Max: 200mA
- Efficiency: Approx. 82%
- Isolation Voltage: 1500 VDC input/output
- Ripple and Noise: 80 mVp-p max.
- Operating Temperature Range: -40°C to +85°C
- Case Material: UL 94V-0 rated non-conductive plastic
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Surge Voltage: 25V max. for 1 sec.
- MTBF: >1 million hours
- Certifications: UL, cUL, IEC/EN 60950-1
- Input/Output Capacitance: 1000 pF typical
- Soldering Temperature: Max 260°C for 10 sec.
- Weight: 13.0 g
Buy the Traco Power TEN 6-1223N – Reliable Dual Output Power Supply for Industrial Applications
Purchase the Traco Power TEN 6-1223N dual output DC/DC converter online today. This 6W power supply features wide input voltage range, high efficiency, UL safety certification, and no minimum load requirement. Perfect for industrial, communication, and power management applications, it offers robust overload protection, internal filtering meeting EN55022 class A standards, and compact dimensions of 20.3mm x 10.2mm x 31.8mm. Reliable and easy to integrate, this converter provides stable ±15VDC outputs with up to 200mA current, ensuring optimal performance across a broad temperature range and supporting critical power needs for diverse electronic equipment.
Order your Traco Power TEN 6-1223N today and ensure reliable power delivery for industrial, communication, and automation projects with high efficiency and safety.
