TRACO POWER THN154822N DC/DC Converter
The THN 15N series is a compact 15 Watt DC/DC converter with a rugged 1” x 1” x 0.4” metal enclosure, featuring a wide 2:1 input voltage range from 9-36 VDC, high efficiency up to 91%, and an integrated EN 55032 class A filter. It operates from -40°C to +70°C without derating, offers input-to-output isolation of 1600 VDC, and includes remote On/Off and trim functions. Suitable for space-constrained industrial, communication, and instrumentation applications, this converter guarantees reliable performance and compliance with UL 62368-1 safety standards.
TRACO POWER THN154822N DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC with 2:1 wide input capacity
- Output Power: 15 Watt
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Input-to-Output Isolation Voltage: 1600 VDC
- Ripple & Noise: 75 mVp-p (5 Vout), 4100 mVp-p (7 Vout), 125 mVp-p (12 Vout)
- Protection: Overload, overvoltage, short circuit, automatic recovery
- Remote On/Off: Open/3-15 VDC on, Short/0-1.2 VDC off
- Dimensions: 1” x 1” x 0.4” (25.4 x 25.4 x 10.16 mm)
- Input Filter: Internal Pi type
- Safety Certification: IEC/EN/UL 62368-1
- Humidity: 5-95% relH, non-condensing
- MTBF: 1,670,000 hours
- Switching Frequency: 220-330 kHz
- Casing Material: Copper, Potting Material: Silicone (UL 94-0)
- Weight: Approximately 16.6 g
Buy the Buy Traco Power THN 15N Series 15 Watt DC/DC Converter Part Number THN154822N Online
Purchase the Traco Power THN 15N Series 15 Watt DC/DC converter online today to benefit from high efficiency, wide input voltage range, and robust design. Its compact metal enclosure fits perfectly into space-critical applications like industrial equipment, communication systems, and instrumentation. Featuring an integrated EN 55032 class A filter, remote On/Off, and excellent thermal performance from -40°C to +70°C without derating, this converter guarantees dependable operation and safety compliance. Get yours now for stable, efficient power conversion tailored to demanding environments.
Order your Traco Power THN 15N Series 15 Watt DC/DC Converter today and ensure reliable power solutions for your industrial projects with high efficiency and space-saving design.
Frequently Asked Questions
Where can I buy TRACO POWER THN154822N?
You can click on the BUY or RFQ button to purchase THN154822N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN154822N?
You can download the THN154822N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN154822N?
TRACO POWER
