TRACO POWER THN301213 DC/DC Converter
The THN 30 Series is a compact and highly efficient 30W DC/DC converter module suitable for space-constrained industrial, communication, and instrumentation applications. It features an ultra-compact size of 1.0” x 1.0” x 0.4”, wide 2:1 input voltage range, and delivers precisely regulated output voltages with up to 92% efficiency. Designed for reliable operation in temperatures up to 85°C, it includes features such as remote On/Off, over-temperature protection, and excellent isolation (1500 VDC). Its robust metal case ensures durability in demanding environments.
TRACO POWER THN301213 DC/DC Converter Specifications:
- Power: 30W
- Input Voltage Range: 12 V, 24 V, 48 V models with start-up voltage <9 V, <18 V, <36 V respectively
- Output Voltage Options: 3.3 V, 5 V, 9-18 V, 12 V, 15 V, 24 V, +12 V, +15 V; adjustable ±10-20%
- Max Output Current: Ranges up to 7000 mA depending on model
- Efficiency: Up to 92% at full load
- Operating Temperature Range: -40°C to +85°C with heat sink, -40°C to +80°C without
- Isolation Voltage: 1500 VDC input/output, 11000 VDC input/case
- Dimensions: 1.0” x 1.0” x 0.4” (25.4 x 25.4 x 10.16 mm)
- No load input current: 8-12 mA depending on model
- Ripple & Noise: 75 mVp-p typical
- Overvoltage & Overcurrent Protection: Yes, with hiccup mode
- Switching Frequency: 275-330 kHz depending on model
- Shock & Vibration: MIL-STD-810F compliant
- Certifications: UL/cUL 60950-1, RoHS 2011/65/EU
Buy the Traco Power Series THN: High Efficiency DC/DC Converter 30 Watt
Purchase the Traco Power THN 30 Series DC/DC converter online today and enjoy a reliable, high-efficiency power solution for industrial and communication systems. Its compact size, wide input voltage range, and excellent thermal performance make it ideal for demanding applications requiring space-saving design. With features like remote On/Off, over-temperature protection, and robust isolation, this converter ensures long-lasting durability and optimal performance even in high-temperature environments. Order now to improve your system’s power management with confidence.
Get Traco Power THN 30 Series converter today—built for precision, durability, and optimal performance in space-constrained environments.
