TRACO POWER TIM21219 Medical Power Converter
The TIM 2 series is a compact 2 Watt DC/DC converter range housed in DIP-16 packages, designed for medical applications with reinforced isolation of 5000 VACrms. It features low leakage current under 2 pA, extended temperature tolerance from -40°C to 95°C, and compliance with IEC 60601-1 standards for safety and EMC immunity. These converters accommodate a wide input voltage range, provide various output voltages, and include protections such as overvoltage, short circuit, and under-voltage shutdown, making them ideal for medical and communication equipment.
TRACO POWER TIM21219 Medical Power Converter Specifications:
- Input Voltage Range: 3.3 VDC to 48 VDC with surge voltage up to 100 V
- Output Voltages: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V with various current ratings
- Efficiency: Up to 81%
- Isolation Voltage: 5000 VAC, reinforced insulation
- Operating Temperature: -40°C to +95°C, derating above 90°C at 6.7%/K
- Leakage Current: Less than 2 pA at 240 VAC
- Dimensions: Typical case size 14.4 mm x 10.16 mm, height 7 mm
- Protection: Overvoltage, short circuit, under-voltage shutdown, transient response within 500 μs
- Compliance: IEC/EN/ES 60601-1, IEC 60601-1-2, EN55032 Class A, MIL-STD-810F shock and vibration
- Soldering Temperature: 260°C for 10 seconds
- MTBF: 6,809,000 hours
Buy the Buy Traco Power DC/DC Converter TIM 2 Series Part Number TIM21219 Online
Experience reliable power conversion with the Traco Power TIM 2 Series, a 2 Watt DC/DC converter designed for medical applications. Featuring reinforced insulation of 5000 VACrms, ultra-low leakage current under 2 pA, and a wide operating temperature range, this compact converter ensures safety, efficiency, and durability. It is compliant with IEC 60601-1 safety standards and offers protection features including overvoltage, short circuit, and undervoltage shutdown. Ideal for medical and sensitive electronic equipment, order online today for trusted performance and peace of mind in your critical applications.
Get Traco Power TIM 2 Series DC/DC Converter TIM21219 today—built for medical precision with reinforced insulation and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER TIM21219?
You can click on the BUY or RFQ button to purchase TIM21219 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM21219?
You can download the TIM21219 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM21219?
TRACO POWER
