TRACO POWER TEN64812N DC-DC Converter
The TEN 6-4812N from TracoPower is a high-performance, 6W single-output DC-DC converter housed in a 24-pin DIP package. It offers an optimized balance of cost and performance, featuring overload protection, internal filtering for EN55022 Class A compliance, no minimum load requirement, and high efficiency. This converter is a cost-effective and easy-to-implement solution, compatible as a drop-in replacement for similar DIP-24 standard modules. It supports a wide 2:1 input voltage range of 36VDC to 75VDC, with an output voltage of 12VDC and a maximum current of 500mA. The device provides automatic recovery from short circuits, with an isolation voltage of 1500VDC, and is protected against surge voltages up to 100V for 1 second. It features a UL 94V-0 rated non-conductive plastic case with UL epoxy potting. Typical applications include distributed power architectures, workstations, computer equipment, and communication systems. Key specifications include an efficiency of 84%, a switching frequency of 330kHz, and operating temperature from -40°C to +85°C.
TRACO POWER TEN64812N DC-DC Converter Specifications:
- Input Voltage Range: 36VDC to 75VDC, 2:1 ratio
- Output Voltage: 12VDC
- Output Current Max: 500mA
- Efficiency: 84% typical
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +85°C
- Switching Frequency: 330kHz
- Input Current at No Load: 20 mA (24V models)
- Input Current at Full Load: 610 mA (24V models)
- Ripple and Noise: 80 mVp-p max.
- Case Material: UL 94V-0 non-conductive plastic
- Potting Material: UL recognized epoxy
- Protection: Overload, short circuit, surge up to 100V for 1 sec.
- Dimensions: 24-pin DIP package, typical size 41.0mm x 22.0mm
- Soldering Temperature: Max 260°C (typ. 10 sec.)
Buy the TracoPower Series TEN 6N DC-DC Converter: TEN64812N
Upgrade your power supply with the TracoPower TEN64812N, a 6W high-performance, single-output DC-DC converter featuring 84% efficiency, 1500VDC isolation, and no minimum load requirement. Its compact 24-pin DIP package makes installation simple and reliable. Designed for distributed power, communication systems, and computer equipment, it provides stable 12V output with overload and surge protection. With operation from -40°C to +85°C and UL compliance, this converter ensures robust, safe, and efficient power conversion for today's demanding applications.
Get TracoPower TEN64812N today—built for high efficiency, reliability, and easy integration in industrial and communication power systems.
