TRACO POWER TEN64821N Dual-Output Power Converter
The Ten 6-4821N from TracoPower is a high-performance, dual-output 6W DC-DC converter housed in a 24-pin DIP package. Designed for optimal cost and performance, it features overload protection, internal filtering compliant with EN55022 Class A, and does not require a minimum load. The converter offers high efficiency, a wide input voltage range of 36VDC to 75VDC, and tight output voltage regulation with an accuracy of ±2%. It provides output voltages of ±5VDC with a maximum current of ±500mA, and includes continuous, automatic recovery short circuit protection. The device has an UL 94V-0 rated non-conducting plastic case with UL 94V-0 epoxy potting, making it suitable for distributed power architectures, workstations, computer, and communication equipment. Operating at a switching frequency of 330kHz, it ensures reliable performance across a temperature range of -40°C to +85°C. The converter also features an input-to-output isolation voltage of 1500VDC, with a resistance greater than 1000 MΩ at 500VDC, and complies with UL/cUL 60950-1 and IEC/EN 60950-1 standards.
TRACO POWER TEN64821N Dual-Output Power Converter Specifications:
- Input voltage range: 36VDC to 75VDC
- Output voltage: ±5VDC
- Output current: ±500mA
- Efficiency: Up to 84%
- Isolation voltage: 1500VDC
- Isolation resistance: >1000 MΩ at 500VDC
- Switching frequency: 330kHz
- Operating temperature: -40°C to +85°C
- Case material: UL 94V-0 rated plastic with epoxy potting
- MTBF: >1 million hours
- Dimensions: 24-pin DIP package, compact design
- Safety standards: UL/cUL 60950-1, IEC/EN 60950-1
- Certifications: UL Listed, RoHS compliant
- Soldering temperature: Max 260°C for 10 seconds
- Humidity: Up to 95% non-condensing
- Weight: 13 g
Buy the TracoPower TEN64821N – Reliable Dual-Output 6W DC-DC Converter for Industrial Applications
Enhance your industrial and communication equipment with the TracoPower TEN64821N dual-output 6W power converter. Featuring high efficiency, wide input voltage range from 36VDC to 75VDC, and an UL 94V-0 rated non-conducting plastic case, this converter ensures reliable power delivery. Its compact DIP-24 package simplifies integration, while overload protection and internal filtering meet stringent EN55022 Class A standards. Suitable for demanding environments, it operates from -40°C to +85°C, providing stable ±5V outputs at a maximum of 500mA with automatic short circuit recovery for continuous operation.
Buy TracoPower TEN64821N now and experience unmatched reliability and performance in your power supply solutions.
