TRACO POWER TES12423 DC/DC converter
The TES 1 Series 1 Watt DC/DC converters are compact, high-efficiency power modules designed for industrial applications requiring isolated voltages. They feature a small SMD package, operate across -40°C to +90°C, and support lead-free reflow solder processes. With input voltages of 5, 12, and 24 VDC, and various output voltages, these converters are ideal for ground loop elimination, noise reduction, and voltage conversion in distributed power systems. They provide up to 80% efficiency and have a 1500 VDC isolation voltage for safety and noise immunity.
TRACO POWER TES12423 DC/DC converter Specifications:
- Input voltage: 5 VDC, 12 VDC, 24 VDC
- Output voltages: 3.3 VDC, 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC
- Output current: up to 435 mA
- Efficiency: up to 80%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +90°C
- Storage temperature: -50°C to +125°C
- Case material: UL94V-0 rated plastic
- Weight: single output models 1.7 g, dual output models 2.0 g
- Peak reflow temperature: 245°C
- Moisture sensitivity level: level 2 (J-STD-033B.1)
- Washing process: not recommended
- Ripple & noise: max 120 mVpp (20 MHz bandwidth)
Buy the TracoPower TES12423 – Reliable DC/DC for Industrial Applications
Purchase the TracoPower TES12423 online today to enjoy a compact, efficient, and reliable DC/DC conversion solution suitable for industrial applications. These converters provide galvanic isolation up to 1500 VDC, support multiple input and output voltages, and operate across a wide temperature range, ensuring consistent performance even in demanding environments. Designed for surface-mount assembly with lead-free reflow soldering, they are perfect for noise reduction, voltage isolation, and distributed power systems. Secure your supply chain by ordering online and benefit from quick delivery and trusted quality.
Get TracoPower TES12423 today—built for precision with high efficiency and extensive temperature range for industrial use.
