TRACO POWER TMM40112C Power Module
The TMM 40 Series power modules are fully encapsulated 40 Watt AC/DC supply units with low profile plastic cases designed for PCB and chassis mounting. These modules meet rigorous medical safety standards, including 2 x MOPP isolation per IEC/EN 60601-1 3rd edition, and industrial safety standards UL 60950-1 and UL 508. Offering high efficiency, compact size, and wide operating temperature range from -40°C to +60°C (derating to 75°C at 50% load), they ensure reliable performance in medical, industrial, transportation, and commercial applications with excellent EMI/EMC compliance and safety features.
TRACO POWER TMM40112C Power Module Specifications:
- Output Power: 40 Watt
- Output Voltage: 12 VDC / 3330 mA, 15 VDC / 2660 mA, 24 VDC / 1660 mA, 5 VDC / 8000 mA
- Input Voltage Range: 85 - 264 VAC, 120 - 370 VDC
- Input Frequency: 47 - 440 Hz
- Efficiency: Up to 85%
- No-Load Power Consumption: <0.3W
- Operating Temperature: -40°C to +60°C (derates to 75°C at 50% load)
- Protection: Over-temperature, overload, short circuit
- Isolation Voltage: 4000 VAC (Input/Output)
- Dimensions: PCB mount: 79.2 x 27.94 x 19 mm; Chassis mount: similar form factor
- MTBF: >200,000 hours
- Certifications: UL 60950-1, IEC/EN 60950-1, IEC/EN 60601-1 3rd ed., UL 508
- Safety Class: II, according to IEC/EN 60536
- EMC Standards: EN 55022, FCC Part 15 Level B, EN 55011 Class B
Buy the Buy TracPower Power Modules Part Number TMM40112C Online
Purchase the TracPower TMM 40112C power module online today to ensure a dependable, high-efficiency power supply solution for your medical, industrial, or commercial applications. Engineered to meet strict safety and EMI standards, this 40W AC/DC unit offers a wide input voltage range, low no-load power consumption, and wide temperature operation from -40°C to +60°C. Its compact design and robust safety features make it ideal for demanding environments, providing peace of mind and consistent performance in your projects.
Buy TracPower TMM 40112C now and experience reliable medical-grade power supply performance with high efficiency and wide operating temperature range.
Frequently Asked Questions
Where can I buy TRACO POWER TMM40112C?
You can click on the BUY or RFQ button to purchase TMM40112C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMM40112C?
You can download the TMM40112C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMM40112C?
TRACO POWER
