TRACO POWER TEN84811WI DC/DC Converter
The TEN 8WI series offers high-performance 8 Watt DC/DC converter modules with ultra-wide 4:1 input voltage ranges, suitable for industrial, transportation, and telecom applications. Featuring DIP-24 metal packages, they provide operational efficiencies up to 88%, EN 50155 approval for railway use, and are resilient to thermal shocks and vibrations. Standard features include remote On/Off, under-voltage lockout, short circuit, and over-voltage protections. These compact, shielded metal case converters are ideal for wireless networks, control systems, and measurement equipment in challenging environments, ensuring reliable power supply with minimal noise and high EMC compliance.
TRACO POWER TEN84811WI DC/DC Converter Specifications:
- Power: 8 Watts
- Input Voltage Range: 9-36 VDC, 18-75 VDC, 43-160 VDC with ultra-wide 4:1 ratio
- Input Current (full load): 10-210 mA depending on model and voltage
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +85°C
- Isolation: 1500 VDC input/output
- Control: Remote On/Off, under-voltage lockout at 8-42 VDC
- Switching Frequency: approximately 300 kHz
- Dimensions: Standard DIP-24 package, weight approx. 18g
- Protection features: Overvoltage, overcurrent, short circuit, and thermal protection
- Certifications: EN 50155, UL/cUL 60950-1, IEC/EN 60950-1, RoHS, Reach, EN 45545-2 flammability
- Construction: Copper case, nickel plated, potting with UL94V-0 epoxy, insulated baseplate
- Temperature Range: -40°C to +85°C operating, with power derating above 70°C
Buy the Buy TRACOPOWER TEN 8WI Series 8 Watt Part Number TEN84811WI Online
Purchase the TRACOPOWER TEN 8WI Series TEN84811WI online today to benefit from 8 Watts of high-efficiency power in a compact, industrial-grade design. With input ranges from 18 to 75 VDC, these converters offer stable voltage regulation, low ripple, and advanced protections including over-voltage, short circuit, and thermal safeguards. Certified for railway and industrial standards, they deliver excellent EMC performance and reliability in rugged environments. Secure your supply chain with fast online ordering, ensuring continuous operation of control systems, telecom equipment, and measurement devices in critical applications.
Order your TRACOPOWER TEN 8WI Series TEN84811WI today and ensure reliable power with high efficiency in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN84811WI?
You can click on the BUY or RFQ button to purchase TEN84811WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN84811WI?
You can download the TEN84811WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN84811WI?
TRACO POWER
