TRACO POWER TEP2004815WIRCMF Industrial Power Converter
The TEP 200WIR Series is a high-performance isolated DC/DC converter family designed for industrial and railway applications. It features ultra-wide 4:1 input voltage ranges, up to 91% efficiency, EMI filtering, and EN 50155 approval. The modules are chassis mount with screw terminals, soft start, remote On/Off, and over-temperature protections. Suitable for telecom, datacom, industrial control, and onboard power systems, these converters operate reliably at temperatures from -40°C to +105°C, with optional external components for enhanced performance and wiring versatility.
TRACO POWER TEP2004815WIRCMF Industrial Power Converter Specifications:
- Input Voltage Range: 9-36 VDC, 18-75 VDC, 43-160 VDC, 28 V, 48 V, 110 V models
- Output Voltage Adjustment: +10% / -20% via external resistor
- Maximum Output Current: 75A for 24 V, 37A for 48 V, 16A for 110 V models
- Efficiency: Up to 91%
- Isolation Voltage: 2,250 VDC (Input/Output), 1600 VDC (Input/Case)
- Input Current at No Load: 10-45 mA depending on model
- Start-Up Voltage: 9-43 VDC depending on model
- Surge Voltage: 50 VDC to 185 VDC
- Operating Temperature Range: -40°C to +75°C, max case temp +115°C
- Humidity: 95% rel. H max.
- MTBF: 300,000 hours
- Safety Standards: UL 60950-1, EN 60950-1, EN 50155
- Switching Frequency: 250 kHz
- Physical Material: Metal or aluminum base with plastic casing, epoxy potting (UL94V-0)
Buy the TracoPower TEP200WIR – Reliable Industrial DC/DC Converter for Railway Applications
Order the TracoPower TEP200WIR Series online today to ensure your industrial or railway systems operate with high efficiency and reliability. These high-performance DC/DC converters, featuring ultra-wide input voltage ranges, EN 50155 approval, and up to 91% efficiency, are designed for demanding environments. Equipped with protective features including over-temperature, reverse input voltage, and remote On/Off, they ensure safety and consistent operation. With a robust construction, they are ideal for telecom, datacom, control, and onboard power applications, delivering stable power even under extreme conditions.
Buy TracoPower TEP200WIR now and experience unmatched reliability and performance for industrial and railway power systems.
Frequently Asked Questions
Where can I buy TRACO POWER TEP2004815WIRCMF?
You can click on the BUY or RFQ button to purchase TEP2004815WIRCMF from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEP2004815WIRCMF?
You can download the TEP2004815WIRCMF datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEP2004815WIRCMF?
TRACO POWER
