TRACO POWER TES10513 DC-DC Converter
The TES 1 Series is a compact 1-Watt DC/DC converter ideal for applications requiring isolated voltage. Featuring a small SMD package, it offers high efficiency of up to 80%, wide operating temperature from -40°C to +90°C, and is qualified for lead-free reflow soldering. Options include single and dual output configurations with input voltages of 5, 12, and 24 VDC, making it suitable for ground loop elimination, noise reduction, digital interface isolation, and distributed power systems in industrial and embedded applications. Its robust design ensures reliable performance even in demanding environments, and it’s supplied in tape and reel for automated manufacturing.
TRACO POWER TES10513 DC-DC Converter Specifications:
- Input Voltage: 5, 12, 24 VDC
- Output Voltage Options: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V
- Output Current Max.: 435 mA
- Efficiency: Up to 80%
- Operating Temperature Range: -40°C to +90°C
- Isolation Voltage: 1500 VDC (Input/Output)
- Isolation Resistance: >1,000 Mohm
- Ripple and Noise: 120 mVpp max.
- Dimensions: Small SMD package, weight approx. 1.7g to 2.0g
- Compliance: RoHS, UL94V-0 rated casing, Peak package temperature 245°C
- MTBF: >2,000,000 hours
- Humidity: 95% relative, non-condensing
- Switching Frequency: 100 kHz typical
Buy the Buy TRACO POWER TES 1 Series Part Number TES10513 Online
Purchase the TRACO POWER TES 1-0513 5 VDC DC/DC converter online today. This compact, high-efficiency power module provides 200 mA of output current with 80% efficiency, suitable for industrial applications, noise reduction, and digital interface isolation. It features a small SMD package, wide operating temperature from -40°C to +90°C, and high reliability with an MTBF of over 2 million hours. Ideal for automated manufacturing, it supports lead-free reflow soldering and ensures durability and precise voltage regulation in demanding environments.
Order your TRACO POWER TES 1-0513 high-efficiency 5 VDC converter today and ensure reliable voltage isolation for your industrial and embedded projects.
Frequently Asked Questions
Where can I buy TRACO POWER TES10513?
You can click on the BUY or RFQ button to purchase TES10513 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TES10513?
You can download the TES10513 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TES10513?
TRACO POWER
