TRACO POWER THD102422N DC/DC Power Converter
The THD series from TracoPower are 10W isolated DC/DC converters housed in a low-profile 24-pin DIP package, suitable for industrial and communication applications. They feature a wide input voltage range of 2:1, low ripple and noise, and full protections including short circuit and overvoltage. With efficiencies up to 88%, they operate from -40°C to +71°C, and provide an I/O isolation voltage of 1500VDC for 60 seconds. These reliable converters are certified under UL and IEC safety standards, ideal for space-constrained power supply designs.
TRACO POWER THD102422N DC/DC Power Converter Specifications:
- Input Voltage Range: 12VDC, 24VDC, 48VDC
- Output Voltages: 3.3VDC, 5.1VDC, 12VDC, ±12VDC, ±15VDC
- Output Current: Up to 3A depending on model
- Efficiency: Up to 88%
- Ripple & Noise: 85mV peak-to-peak at 20MHz bandwidth
- Switching Frequency: 400kHz
- Isolation Voltage: 1500VDC for 60 seconds
- Mechanical Dimensions: 20.3mm x 10.2mm x 31.8mm
- Operating Temperature: -40°C to +71°C
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, IEC 60950-1
- Protection: Short circuit, overvoltage, overcurrent
- Materials: Metal casing with non-conductive baseplate
- Soldering Temp (max): 260°C for 10 sec
Buy the TracoPower Series THD DC/DC: THD102422N
Purchase the TracoPower THD102422N online today for high-performance, space-saving power conversion. Designed for industrial, communication, and instrumentation systems, this 10-watt isolated converter offers a wide input voltage range, efficiencies up to 88%, and robust protections like short circuit and overvoltage. Its compact DIP-24 package ensures easy integration into limited PCB spaces. Certified standards guarantee safety and reliability. Improve your electronic design with this dependable, efficient, and compact power supply solution—order now for quick delivery and superior performance.
Get TracoPower THD102422N today—built for industrial-grade power regulation and long-lasting reliability.
Frequently Asked Questions
Where can I buy TRACO POWER THD102422N?
You can click on the BUY or RFQ button to purchase THD102422N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD102422N?
You can download the THD102422N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD102422N?
TRACO POWER
