TRACO POWER TES12412 DC/DC Converter
The TES 1 Series 1 Watt DC/DC converters are compact and efficient power modules ideal for isolation, noise reduction, and voltage conversion in distributed systems. They feature a small SMD package with a standard footprint, making them suitable for automated surface-mount assembly. The converters support input voltages of 5, 12, and 24 VDC, with multiple output options including single and dual outputs. They are qualified for lead-free reflow soldering, operate within -40°C to +90°C, and provide up to 80% efficiency, ensuring reliable performance in demanding environments.
TRACO POWER TES12412 DC/DC Converter Specifications:
- Input Voltage: 5 VDC, 12 VDC, 24 VDC
- Output Voltage Options: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V
- Output Current: Up to 435 mA
- Isolation Voltage: 1500 VDC
- Efficiency: Up to 80%
- Operating Temperature Range: -40°C to +90°C
- Case Material: Plastic (UL94V-0 rated)
- Weight: Single output models 1.7 g, dual output models 2.0 g
- Lead-free reflow solder process qualified, max package temperature 245°C
- Moisture sensitivity level: MSL level 2
- Ripple and Noise: 120 mVpp max
- Switching Frequency: 100 kHz typical
- Isolation Resistance: >1,000 Mohm
- Dimensions: Compact SMD footprint suitable for automation
Buy the Buy TRACOPOWER TES 1 Series 1 Watt DC/DC Converter Part Number TES12412 Online
Purchase the TRACOPOWER TES 12412 Series 1 Watt DC/DC converter online today to enjoy a reliable, high-efficiency power solution that supports multiple input and output options. Designed for demanding industrial environments, this compact SMD module provides up to 80% efficiency, high frequency switching, and robust electrical isolation of 1500 VDC. It is qualified for lead-free reflow soldering, suitable for automated manufacturing. With a small footprint and excellent temperature range, it’s ideal for digital interfaces, noise reduction, and distributed power systems, ensuring longevity and dependable operation.
Order your TRACOPOWER TES 12412 Series 1 Watt DC/DC converter today and ensure reliable, efficient power isolation for your electronic projects.
Frequently Asked Questions
Where can I buy TRACO POWER TES12412?
You can click on the BUY or RFQ button to purchase TES12412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TES12412?
You can download the TES12412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TES12412?
TRACO POWER
