TRACO POWER THI31223 High Isolation DC-DC Converter
The THI 3 series offers high isolation DC/DC converters designed for medical and industrial applications, providing reinforced insulation, fully regulated output, and compliance with safety standards such as IEC 60601-1 and IEC 60950-1. Encapsulated in a DIP-24 package, these 3-watt converters support input voltages of 5, 12, and 24 VDC, available in single or dual output models. They feature low leakage current, short circuit protection, and are suitable for applications requiring certified safety and insulation standards, ensuring reliable and safe operation.
TRACO POWER THI31223 High Isolation DC-DC Converter Specifications:
- Input Voltage Range: 5 VDC, 12 VDC, 24 VDC
- Output Power: 3 Watts
- Efficiency: Up to 64%
- Isolation Voltage: 4000 VACrms rated, 300 VACrms working
- Operating Temperature Range: -40°C to +75°C
- Ripple and Noise: 50 mVpk-pk (20 MHz bandwidth)
- Short Circuit Protection: Yes, automatic recovery
- Temperature Coefficient: +0.02 %/K
- Conducted Noise: EN 55022, class A, FCC level A
- Isolation Capacitance: Input/Output 20 pF typical
- Dimensions: Encapsulated DIP-24 package, 23.0 x 15.5 x 17.0 mm
- Input Fuse: 0.5A to 2A (recommended)
- Soldering Temperature: Max 260°C for 10 seconds
- Switching Frequency: 25 - 60 kHz
- Compliance: IEC/EN 60601-1, IEC 60950-1, RoHS
- MTBF: >1 million hours at +25°C
Buy the Buy TracoPower THI 3 Series Part Number THI31223 Online
Purchase the TracoPower THI 3 series high isolation DC-DC converters online for your medical and industrial applications. These certified units offer reinforced insulation, regulated output, and low leakage current, ensuring safety and reliability. Designed for medical safety standards like IEC 60601-1 and IEC 60950-1, they provide robust performance with efficiencies up to 64%. Their encapsulated DIP-24 format is ideal for space-constrained environments, supporting input voltages of 5, 12, and 24 VDC with various dual or single output configurations. Built to last, they feature short circuit protection and long MTBF, making them perfect for critical applications requiring certified safety standards.
Get TracoPower THI 3 Series THI31223 today—built for medical safety, high insulation, and reliable performance in healthcare and industrial equipment.
Frequently Asked Questions
Where can I buy TRACO POWER THI31223?
You can click on the BUY or RFQ button to purchase THI31223 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THI31223?
You can download the THI31223 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THI31223?
TRACO POWER
