TRACO POWER THL101222 DC/DC Converter
The THL 10 series from TracoPower features 10W DC/DC converters in a compact 1 x 1 inch metal case, designed as pin-to-pin replacements for 1 x 2 inch formats. They provide a wide 2:1 input voltage range, an industry-standard pinout, and an input filter compliant with EN 55022 Class A standards without external components. Offering short circuit and overvoltage protection, these converters operate over -40°C to +80°C, up to +85°C with a heat sink. Suitable for instrumentation, industrial electronics, and communication systems, models support various input voltages and deliver a range of output voltages with efficiencies up to 89% and 1500VDC isolation.
TRACO POWER THL101222 DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 12VDC, 24VDC, 48VDC, ±15V, ±12V, ±5V
- Output Voltage: 3.3V, 5.1V, 12V, 15V, ±5V, ±12V, ±15V
- Maximum Output Current: 2.5A (at 3.3V), 2A (at 5V), 830mA (at 12V)
- Efficiency: Up to 89%
- Isolation Voltage: 1500 VDC (60 seconds)
- Isolation Resistance: >1000 MΩ at 500VDC
- Capacitive Load: Up to 4700 pF depending on model
- Ripple & Noise: 80-100 mVp-p
- Switching Frequency: ~300 kHz
- Operating Temp Range: -40°C to +80°C, up to +85°C with heat sink
- Dimensions: 1” x 1” x 0.53” (25.4 x 25.4 x 13.5 mm)
- Case Material: Metal, with non-conductive FR4 baseplate
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
Buy the Buy TracoPower DC/DC Converter Part Number THL101222 Online
Order the TracoPower THL 10 series 10W DC/DC converter online today to enjoy high efficiency, wide input voltage range, and robust protections suitable for industrial electronics, instrumentation, and communication applications. Designed with industry-standard pinout and a compact form factor, these converters ensure easy integration into your projects. Benefit from a 3-year warranty, UL and IEC safety certifications, and reliable operation across a broad temperature range. Get yours now for a dependable power solution that meets stringent global standards.
Buy TracoPower THL101222 now and experience efficient, reliable power conversion for industrial and communication systems.
Frequently Asked Questions
Where can I buy TRACO POWER THL101222?
You can click on the BUY or RFQ button to purchase THL101222 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL101222?
You can download the THL101222 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL101222?
TRACO POWER
