TRACO POWER TEN82423 Industrial DC-DC Converter
The TEN 8-2423 is a dual-output, board-mount isolated DC-DC converter with tightly regulated output voltages and a wide input voltage range of 2:1. This 8W high-performance converter features an industry-standard footprint, short-circuit protection, and high efficiency of up to 85%. It includes an input filter compliant with EN 55022, Class A, remote on/off capability, and a shielded metal casing with an insulated baseplate. Operating reliably from -40°C to +85°C, it is ideal for compact, industrial electronics needing isolated, regulated power supplies.
TRACO POWER TEN82423 Industrial DC-DC Converter Specifications:
- Input Voltage Range: 12 VDC to 48 VDC, Surge Voltage: 36 V to 100 V max.
- Output Voltages: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, with max currents up to 2000 mA.
- Efficiency: Up to 85%.
- Isolation Voltage: 1500 VDC.
- Operating Temperature Range: -40°C to +85°C.
- Input Current (full load): 360 mA (24 VDC), 720 mA (12 VDC), 180 mA (48 VDC).
- Conducted Noise: EN 55022 Level A.
- Dimensions: Industry standard DIP-24 footprint, device weight 17 g.
- Safety Certifications: UL/cUL 60950-1, IEC/EN 60950-1.
- Environmental Compliance: RoHS 2011/65/EU, Reach.
- Mechanical Features: Copper, nickel-plated casing with epoxy potting, insulated plastic baseplate.
- Remote On/Off: 5–12 VDC or open circuit for ON, Short circuit or 0–1.2 VDC for OFF.
- Protection: Short-circuit, overload, and transient immunity.
Buy the TracoPower TEN 8 Series – Reliable Industrial DC-DC Converter for Power Regulation
Purchase the TracoPower TEN 8 series 8W DC-DC converter today and ensure reliable, high-efficiency power regulation for your industrial or communication systems. With a wide input voltage range, compact design, and robust features like remote On/Off, short-circuit protection, and compliance with safety and EMI standards, it is ideal for demanding environments requiring isolated, tightly regulated voltages. Trust in TracoPower’s quality for durable and efficient power solutions essential for modern electronic applications.
Get TracoPower TEN 8 Series DC-DC converter today—built for precision and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TEN82423?
You can click on the BUY or RFQ button to purchase TEN82423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN82423?
You can download the TEN82423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN82423?
TRACO POWER
