TRACO POWER TMM24124C medical power supply
The TMM 24 Series is a 24-watt fully encapsulated AC/DC power supply module designed for medical, industrial, and transportation applications. It features double I/O isolation according to IEC/EN 60601-1 3rd edition for 2x MOPP safety, ensuring reliable performance in demanding environments. With an operating temperature range of -40°C to +65°C, high efficiency, and low no-load power consumption (<0.3W), it provides protection against over-temperature, overload, and short circuits. Certified for medical safety, UL 60950-1, and RoHS compliant, this module guarantees durability and safety.
TRACO POWER TMM24124C medical power supply Specifications:
- Power output: 24 W, 24 VDC / 1000 mA
- Input voltage: 100-240 VAC, 85-264 VAC (universal), 120-370 VDC
- Input frequency: 47-440 Hz
- Efficiency: 85%
- Leakage current: 80 pA typ.
- No-load power consumption: <0.3W
- Operating temperature: -40°C to +65°C, derates above 65°C
- Isolation voltage: 4000 VAC input/output
- Protection: Over-temperature shutdown, overload, short circuit
- Certifications: UL 60950-1, IEC/EN 60601-1, RoHS
- Casing: Fully encapsulated UL 94V-0 plastic
- Dimensions: Compact and lightweight, PCB or chassis mounting options
- Humidity: 95% non-condensing
- Altitude: Up to 5000 m
- Switching frequency: 132 kHz
- MTBF: >400,000 hours at +25°C
- Protection class: II, IEC/EN 60536
Buy the TracoPower TMM24124C – Reliable Medical-grade Power Supply for Industrial Applications
Experience the dependable performance of the TracoPower TMM24124C medical-grade power supply, engineered for industrial and healthcare applications. Its fully encapsulated design ensures durability and safety, meeting stringent standards like IEC/EN 60601-1 3rd edition with 2x MOPP certification. Operating efficiently from -40°C to +65°C, it offers low no-load power (<0.3W), and protection against overload, short circuit, and over-temperature. Perfect for demanding environments, this compact power module combines safety, reliability, and compliance for long-term use.
Get TracoPower TMM24124C today—built for medical, industrial, and transportation excellence with high efficiency and robust safety standards.
Frequently Asked Questions
Where can I buy TRACO POWER TMM24124C?
You can click on the BUY or RFQ button to purchase TMM24124C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMM24124C?
You can download the TMM24124C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMM24124C?
TRACO POWER
