TRACO POWER TEN401223N High-Performance Industrial Power Module
The TEN 4ON Series are high-performance isolated DC/DC converter modules delivering 40W of power in a compact 1" x 2" x 0.4" package. These converters feature efficiency up to 92%, wide input voltage ranges, and adjustable output voltage via external resistor. They include remote on/off, short circuit, overvoltage protections, and operate from -40°C to +80°C. Suitable for space-constrained mobile, industrial, and communication applications, they meet safety standards IEC 60950-1 and UL 60950-1, with a 3-year warranty, ensuring reliable power conversion in demanding environments.
TRACO POWER TEN401223N High-Performance Industrial Power Module Specifications:
- Power output: 40W
- Input voltage range: 36-75 VDC
- Output voltages: 3.3V, 5V, 9-18V, 12V, 15V, 24V, +12V, +15V, 48V
- Output current max: 8A (for 3.3V, 5V models), 3.33A (for 12V, 15V models), 1.67A (for 24V models), 2.67A (for 48V models)
- Efficiency: up to 92%
- Isolation voltage: 1500 VDC (input/output)
- Operating temperature range: -40°C to +80°C
- Case material: Aluminum with optional heatsink
- Dimensions: 1" x 2" x 0.4"
- Protection: Short circuit, overvoltage, overtemperature
- Isolation capacitance: ~1500 pF
- MTBF: 328,000 hours
- Soldering temperature: 260°C / 10 seconds
- Certifications: IEC/EN 60950-1, UL 60950-1, RoHS compliant
- Remote On/Off control, adjustable output via external resistor
- Weight: Approximately 30g
Buy the TracoPower TEN 4ON – Reliable Power Supply for Industrial Applications
Purchase your TracoPower TEN 4ON series 40 Watt DC/DC converter online today for reliable power conversion. Its high efficiency, wide input range, and protection features make it ideal for space-sensitive applications in industrial, communication, and mobile equipment industries. With adjustable output, remote on/off, and RoHS compliance, it ensures optimal performance, durability, and safety in demanding environments. Get your power supply now and enhance your project's reliability and efficiency with trusted TracoPower quality.
Order your TracoPower TEN 4ON series 40 Watt DC/DC converter today and ensure dependable, efficient power for your industrial electronics and communication projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEN401223N?
You can click on the BUY or RFQ button to purchase TEN401223N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN401223N?
You can download the TEN401223N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN401223N?
TRACO POWER
