TRACO POWER THL102410WI industrial DC-DC converter
The THL 10-2410WI from TracoPower is a 10W DC-DC converter series, designed in a compact 1-inch x 1-inch metal casing with an isolated baseplate. It features an ultra-wide 4:1 input voltage range from 9VDC to 36VDC (nominal 24VDC), delivering a stable 3.3VDC output at up to 2200mA with an typical efficiency of 86%. The converter complies with EN 55022 Class A emissions and provides an industrial standard pinout, making it an easy-to-integrate solution for various industrial applications. Key features include remote On/Off control, short circuit and overvoltage protection, and high I/O isolation with 1500VDC withstand voltage. Suitable for temperature operation up to +75°C or +85°C with an optional heat sink, it is ideal for instrumentation, distributed power architectures, communication, and industrial electronics.
TRACO POWER THL102410WI industrial DC-DC converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 9VDC to 36VDC (nominal 24VDC)
- Output Voltage: 3.3 VDC
- Output Current Max: 2200 mA
- Efficiency: 86% typical
- Isolation Voltage: 1500 VDC
- Operating Temperature Range: -40°C to +75°C, up to +85°C with heat sink
- Input Filter: Meets EN 55022 Class A
- Remote On/Off Control: Yes, 2.5 to 50 VDC for on, 0 to 41 VDC for off
- Dimensions: 1” x 1” x 0.51”
- Weight: 15 g
- Soldering Temperature: Max +260°C / 10s
Buy the TracoPower THL102410WI – Reliable DC-DC Converter for Industrial Applications
Purchase the TracoPower THL102410WI online today and enhance your industrial electronic systems with this compact, highly efficient, and reliable 10W DC-DC converter. Its wide input voltage range, high efficiency, and high isolation voltage make it suitable for instrumentation, communication, and distributed power architectures. Featuring remote On/Off control, short circuit, and overvoltage protection, it ensures safe, stable operation even under demanding conditions. Easy to integrate in tight spaces, it’s your ideal solution for industrial, automation, and control applications. Order now for fast delivery and expert support.
Buy TracoPower THL102410WI now and experience unmatched reliability and performance in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THL102410WI?
You can click on the BUY or RFQ button to purchase THL102410WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102410WI?
You can download the THL102410WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102410WI?
TRACO POWER
