TRACO POWER TXH120COV Power Supply
The TXH series power supplies provide high efficiency up to 93%, compact metal enclosures, and universal input of 90-264 VAC. Designed for cost-critical applications, they feature screw terminal blocks for ease of installation, overvoltage, short circuit, and temperature protections. Models range from 120W to 480W, with adjustable outputs of 12V, 24V, or 48V. They comply with relevant safety and EMC standards, offer auto recovery for overvoltage and temperature protections on higher wattage models, and are suitable for industrial automation, control, and power distribution systems, supporting wide operating temperature ranges.
TRACO POWER TXH120COV Power Supply Specifications:
- Input voltage: 90 - 264 VAC universal, 120 - 370 VDC
- Output power range: 120W to 480W
- Output voltages: 12V, 24V, 48V (models available with 36V on request)
- Efficiency: up to 93%
- Ripple and noise: up to 200mVp-p
- Short circuit protection: indefinite for 120 & 240W models, auto recovery for 360 & 480W
- Overvoltage protection: 120% of Vout, auto recovery for higher wattage models
- Operating temperature: -25°C to +70°C (120W), -20°C to +70°C (480W), -10°C to +70°C (others)
- Humidity: 95% relative, non-condensing
- Isolation voltage: 3,000 to 4,000 VAC depending on model
- Size: 137mm to 1050g for larger models, including optional covers
- Switching frequency: 62.5kHz to 100kHz
- Certifications: UL 60950-1, EN 61000-6-1/6-3, RoHS compliant
- MTBF: over 50,000 hours for lower wattage, over 120,000 hours for higher wattage models
Buy the Buy TRACO Power TXH Series Power Supply Part Number TXH120COV Online
Purchase the TRACO Power TXH120COV power supply online today for a reliable, high-efficiency solution with adjustable output voltages, enclosed metal case, screw terminals, and comprehensive safety features. Designed for industrial and automation applications, this unit offers up to 93% efficiency, wide input range, and protections including overvoltage, short circuit, and overheating. Its compact size and robust construction make it ideal for cost-critical environments. Enjoy fast delivery and full support by buying online now—a perfect choice for long-lasting, stable power supply needs.
Get TRACO Power TXH120COV today—built for high efficiency, reliability, and easy installation in industrial power applications.
